Product Description
Rock Point load Testing Machine
Small MOQ:
we accept small quantity order to supports our cooperation.
Excellent quality with competitive price:
All our products are made in China and with competitive price.
OEM / ODM service:
We can offer OEM & ODM service.
Used to determine moisture content of sand, soil and fine aggregate. The procedure involves the reaction between water and calcium carbide which when mixed together a gas is given off. The gas is directly proportional to the amount of water present in the sample and results in percentage moisture range 0-25% & 0-50%.
This apparatus comprises a two-column fixed crosshead frame and a hand operated hydraulic jack. Pressure applied by the jack extends the piston carrying the lower conical point. The upper point is fixed to the crosshead with a scale mounted on the frame to provide specimen diameter information for use in point load strength index calculations.
| Model | DHY-05 | DHY-10 |
| Jack pressure | 50Mpa | 100Mpa |
| Force transducer range | 5T | 10T |
| Piston diameter | 32mm | 36mm |
| Max sample width | 90mm | 90mm |
| Max piston stroke | 120mm | 160mm |
| Accuracy | 0.001KN. | 0.001KN. |
| Piston area | 9.62cm2 | 10.17cm2 |
| Weight | 45Kg | 50Kg |
| Dimension | 280*270*650(mm) | 280mm×250mm×640mm |
We can ship By EMS,TNT,DHL and others ( door to door)
