Small Machine Lubricant Oil Filtration Vacuum Turbine Oil Purifier Recycling Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1993
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Vacuum Turbine Oil Purifier Machine for Severely Emulsified Lubricating Oil RecyclingNegotiableMOQ: 1 -
High Oil Filtration Efficiency TY Vacuum Turbine Oil Purifier/Ship Oil Purifier/Hydraulic Oil Filtration MachineNegotiableMOQ: 1
-
Hydraulic/Lubricating/Turbine Oil Treatment Vacuum Oil Purifier Machine PriceNegotiableMOQ: 1
-
Emulsification And Dehydration Vacuum Oil Purifier Hydraulic Lubrication Oil PurifierNegotiableMOQ: 1
-
Mini Waste Plastic Oil Regeneration Filter to Get Oil Machine Recycling Machine Oil PurifierNegotiableMOQ: 1
Small Machine Lubricant Oil Filtration Vacuum Turbine Oil Purifier Recycling Machine
Product Description
Product Name :
◆ Strong ability to remove impurities: ultra-large area cylindrical precision filter element, with high filtration accuracy, easy
installation and replacement.
◆ High-efficiency vacuum dehydration and degassing: Duplex-Stereo film evaporation technology
◆ Excellent heating system: carbon fiber electric heater with long service life, low heating surface load, linear temperature
rise, preventing oil cracking, keeping oil uniform heating.
◆ Automatic control to realize unattended, safe and stable working.
◆ Safety interlock protection: oil pump, vacuum pump, heater interlock protection
◆ Humanized instructions: automatic design, and there are instructions such as oil temperature gauge, pressure gauge, vacuum gauge, filter pollution alarm, operating status and so on.
◆ This machine has the advantages of low noise, easy operation, long maintenance interval, low energy consumption, low operating cost, high oil filtration efficiency, long lifetime, etc.
◆ TY Vacuum Turbine Oil Purifier
Application:
◆TY Vacuum turbine oil purifier is mainly used to treat substandard turbine oil, especially suitable for severely emulsified
turbine oil. It can quickly and efficiently remove water, gas and impurities from the oil, The filtered oil quality index reaches the new oil standard to ensure the safe operation of the steam turbine unit. This machine uses special high-molecular material as the filtering medium, it integrates emulsification, dehydration, and impurity removal as a whole. Combined with vacuum separation technology, it can demulsify, dehydrate, remove acid, and remove impurities online. It is the ideal equipment for on-line processing of turbine oil, low viscosity lubricating oil and hydraulic oil. This product is widely used in electric power, machinery, metallurgy, petrochemical, military, paper-making, home appliance manufacturing, hydraulic lubrication and other industrial industries to purify turbine oil, lubricating oil, hydraulic oil, refrigerating machine oil, and mechanical oil. Meet the needs of high-precision oil.
turbine oil. It can quickly and efficiently remove water, gas and impurities from the oil, The filtered oil quality index reaches the new oil standard to ensure the safe operation of the steam turbine unit. This machine uses special high-molecular material as the filtering medium, it integrates emulsification, dehydration, and impurity removal as a whole. Combined with vacuum separation technology, it can demulsify, dehydrate, remove acid, and remove impurities online. It is the ideal equipment for on-line processing of turbine oil, low viscosity lubricating oil and hydraulic oil. This product is widely used in electric power, machinery, metallurgy, petrochemical, military, paper-making, home appliance manufacturing, hydraulic lubrication and other industrial industries to purify turbine oil, lubricating oil, hydraulic oil, refrigerating machine oil, and mechanical oil. Meet the needs of high-precision oil.
Features:
◆ The water separator uses high-molecular coalescing material as filtering medium, which integrates emulsification, dehydration and impurity removal.◆ Strong ability to remove impurities: ultra-large area cylindrical precision filter element, with high filtration accuracy, easy
installation and replacement.
◆ High-efficiency vacuum dehydration and degassing: Duplex-Stereo film evaporation technology
◆ Excellent heating system: carbon fiber electric heater with long service life, low heating surface load, linear temperature
rise, preventing oil cracking, keeping oil uniform heating.
◆ Automatic control to realize unattended, safe and stable working.
◆ Safety interlock protection: oil pump, vacuum pump, heater interlock protection
◆ Humanized instructions: automatic design, and there are instructions such as oil temperature gauge, pressure gauge, vacuum gauge, filter pollution alarm, operating status and so on.
◆ This machine has the advantages of low noise, easy operation, long maintenance interval, low energy consumption, low operating cost, high oil filtration efficiency, long lifetime, etc.
Oil Index After Treatment
Index | Unit | TY-10 | TY-20 | TY-30 | TY-50 | TY-100 | TY-150 | TY-200 | TY-300 | |||||||||
Flow rate | L/H | 600 | 1200 | 1800 | 3000 | 6000 | 9000 | 12000 | 18000 | |||||||||
Working Vacuum | MPa | -0.06～-0.095 | ||||||||||||||||
Working Pressure | MPa | ≤0.4 | ||||||||||||||||
Working Temperature | ℃ | 20 ～80 | ||||||||||||||||
Power Supply | 380V 50HZ,3Ph (or According to user demand) | |||||||||||||||||
Working Noise | dB(A) | ≤65～80 | ||||||||||||||||
Heating Power | Kw | 18 | 18 | 18 | 24 | 48 | 72 | 96 | 120 | |||||||||
Total Power | Kw | 20.5 | 20.5 | 20.5 | 27 | 52.5 | 78 | 102 | 128.5 | |||||||||
Inlet / Outlet | mm | 25 | 25 | 25 | 32 | 40 | 50 | 50 | 65 | |||||||||
Weight | kgs | 450 | 500 | 550 | 600 | 800 | 1000 | 1200 | 1550 | |||||||||
Dimension | L | 1550 | 1550 | 1550 | 1600 | 1650 | 1700 | 1800 | 1850 | |||||||||
W | 1150 | 1150 | 1150 | 1250 | 1350 | 1450 | 1550 | 1650 | ||||||||||
H | 1700 | 1700 | 1700 | 1750 | 1800 | 1800 | 1850 | 1850 | ||||||||||
After Purification | ||||||||||||||||||
Demulsification value | min | ≤15/min(GB/F7035) | ||||||||||||||||
Water Content | ppm | ≤80 | ||||||||||||||||
Gas Content | % | ≤0.1 | ||||||||||||||||
Cleanness | ≤NAS 6 | |||||||||||||||||
Optional Device:
A- Optional PLC control.
B-Oil pump set, vacuum pump set, filter element and electrical parts are selected imported brand products.
C-Flow meter, online moisture monitoring
D- Select the appropriate explosion-proof level according to the working environment (ExdII BT4 / ExdII CT4)
A- Optional PLC control.
B-Oil pump set, vacuum pump set, filter element and electrical parts are selected imported brand products.
C-Flow meter, online moisture monitoring
D- Select the appropriate explosion-proof level according to the working environment (ExdII BT4 / ExdII CT4)
Recommend Products
Multiple Machine to Choose:
◆ZY Single-Stage Transformer Oil Purifier◆ZYD Double Stage Vacuum Insulation Oil Purifier
◆ZJA UHV Insulating Oil Purifier
◆ZYM Trailer-Type Insulating Oil Purifier
◆AD Air Dryer
◆TY Vacuum Turbine Oil Purifier
◆TYA Lubricating Oil Purifier
◆TYF Multifunctional Oil Purifier
◆TYK Phosphate Ester Resistant Oil Purifier
◆TJ Coalescing And Separating Oil Purifier
◆TPF Cooking Oil Purifier
◆TPS Cooking Oil Regeneration Device
◆JZS Waste Oil Regeneration System
◆JZC Waste Oil Refinery Plant
◆CXJ Disc-centrifugal oil purifier
◆LY Plate-Press Oil Purifier
◆JL-E High Viscosity Oil Purifier
◆ZYS On-Load Tap Changer Oil Purifier
◆LUC Portable Oil Purifier
◆NKVW Vacuum Pump Unit
◆JYWL Fuller Earth Filtration Device
◆BZ Insulation Oil Regeneration Device
◆IIJ-II Breakdown Voltage Oil Tester
◆NKEE On-line Oil Moisture Tester
◆BF-03 Kinematics Viscosity Tester
◆BF-01A Open Cup Flash Point Tester
◆BF-02 Closed Cup FlashPointTester
◆Oil purifier’s spare parts
◆ZY Single-Stage Transformer Oil Purifier◆ZYD Double Stage Vacuum Insulation Oil Purifier
◆ZJA UHV Insulating Oil Purifier
◆ZYM Trailer-Type Insulating Oil Purifier
◆AD Air Dryer
◆TY Vacuum Turbine Oil Purifier
◆TYA Lubricating Oil Purifier
◆TYF Multifunctional Oil Purifier
◆TYK Phosphate Ester Resistant Oil Purifier
◆TJ Coalescing And Separating Oil Purifier
◆TPF Cooking Oil Purifier
◆TPS Cooking Oil Regeneration Device
◆JZS Waste Oil Regeneration System
◆JZC Waste Oil Refinery Plant
◆CXJ Disc-centrifugal oil purifier
◆LY Plate-Press Oil Purifier
◆JL-E High Viscosity Oil Purifier
◆ZYS On-Load Tap Changer Oil Purifier
◆LUC Portable Oil Purifier
◆NKVW Vacuum Pump Unit
◆JYWL Fuller Earth Filtration Device
◆BZ Insulation Oil Regeneration Device
◆IIJ-II Breakdown Voltage Oil Tester
◆NKEE On-line Oil Moisture Tester
◆BF-03 Kinematics Viscosity Tester
◆BF-01A Open Cup Flash Point Tester
◆BF-02 Closed Cup FlashPointTester
◆Oil purifier’s spare parts
Company Profile
NAKIN Oil Purifiers:
NAKIN products are widely applied in projects of transformer substation, electric department,steel structure, bridge, auto, railway, aviation, chemicals, petroleum etc. The products are exported to more than 30 countries and areas, such as Europe, America, Middle East, Southeast Asia and so on. Each product of NAKIN is professionally tested, and the machine quality and oil quality are guaranteed. It has achieved a good reputation in the hearts of dealers and end users.
Service Commitment：
CHONGQING NAKIN ELECTROMECHANICAL CO.,LTD will always adhere to the business philosophy of “Responsible for product, Responsible for user, Responsible for sell”, keep the faith to create the national brand, keep innovation, keep improving and keep making the high quality oil purifier&oil filtration products with first-class after-service for getting the customer’s trust and love. Really building a new era in Brand-NAKIN with customers.
Certifications
Product packaging
Why Choose Us
Advanced Technology
Through learning and absorbing foreign advanced vacuum separation technology, combined with more than ten years of manufacturing and user experience, we have the ability to design various types of vacuum oil purifier.At the same time, the company has established long-term technical cooperation relationship with local colleges and universities, and also established long-term cooperation relationship with foreign counterparts, which has strong technical strength.
Reliable Quality
Company has passed ISO9001.2015 quality management system certification and CE European certificate. Our oil purifier machine only use the high quality parts, which is reliable quality and excellent performance. The company has complete testing instruments and testing equipment. All products are strictly tested before leaving the factory to ensure that each product is qualified to leave the factory.
Strong Production Srength
The company has a 3,500-The company has a 3,500-square-meter production workshop. The production equipment includes machine tools, shears, plate rolling machines, bending machines, welding machines, sandblasting machines, cranes, spray booths, paint booths, and other professional equipment. Many years of production experience forging It has a team of highly skilled workers that can deliver every piece of equipment efficiently and with high quality.
Good Compnay Reputation
Honesty and trustworthiness is the foundation of the company's survival and development. Since its establishment 12 years ago, NAKIN Company has always adhered to honesty and integrity for the treatment of employees and customers. NAKIN Company cooperates with thousands of customers. A good reputation is the bridge between the company and its customers, and the driving force for the company's sustainable development.
Professional Sales Team
The company has a professional sales team. Because the company's products have a certain degree of professionalism, the professional sales team can recommend the appropriate oil filtration equipment according to the actual situation of the customer, and also can meet the specific requirements of the customer. , Truly do what customers want, solve customer problems.
Excellent After-Sales Service
Professional after-sales service team, after-sales personnel have many years of oil purifier expertise, including the electrical control part or the mechanical structure part, we can quickly and accurately solve the technical problems encountered by customers. Provide 24hours non-stop after-sales service. Solve user’s problems, providing the online technical support in any time and any place.
FAQ
Q1. Can you please offer sample?
A: Sorry, our products are customized one-to-one according to customer needs, so samples cannot be provided.
Q2. What is your packing method?
A: Generally, our goods packed by wooden box.
Q3. What is your terms of payment?
A: Generally, we use T/T, 30% in advance, balance pay after the machine finish.
Q4. How about your delivery time?
A: Generally, it will take 5 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you customized goods for us?
A: Yes, we can customized by your samples or technical drawings.
Q6. If you have any inspection or test for your goods before delivery?
A: Yes, we do the inspection and test before finished goods.
Q7. Can we visit your factory?
A: Yes, we warmly welcome your visiting, and can pick up you at airport or train station.
A: Sorry, our products are customized one-to-one according to customer needs, so samples cannot be provided.
Q2. What is your packing method?
A: Generally, our goods packed by wooden box.
Q3. What is your terms of payment?
A: Generally, we use T/T, 30% in advance, balance pay after the machine finish.
Q4. How about your delivery time?
A: Generally, it will take 5 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you customized goods for us?
A: Yes, we can customized by your samples or technical drawings.
Q6. If you have any inspection or test for your goods before delivery?
A: Yes, we do the inspection and test before finished goods.
Q7. Can we visit your factory?
A: Yes, we warmly welcome your visiting, and can pick up you at airport or train station.
