First-class Vacuum Pump System Insulating Oil Purifier Transformer Oil Purification
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1993
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ZJA Series UHV Insulating Oil Purifier Ultra-high Voltage Transformer Oil Filtration MachineNegotiableMOQ: 1 -
Trailer-Type Insulating Oil Vacuum Oil Purifier Double Stages Transformer Oil Recycling MachineNegotiableMOQ: 1
-
1800-9000L/H Moble Insulating Oil Filtretion Plant Vacuum Transformer Oil Filter MachineNegotiableMOQ: 1
-
Manufacture Petroleum Recycling Machine and Transformer Oil Refinery Plant With High EfficiencyNegotiableMOQ: 1
-
Nakin Customized Vacuum Machine Oil Purifier High Efficiency Oil Filter Transformer Oil RegenerationNegotiableMOQ: 1
Product Description
Application
ZJA series UHV oil purifier is mainly used in 220KV / 330KV / 500KV / 750KV / 1000KV ultra-high voltage and UHV grid transmission and transformation projects. Due to the high safety characteristics of ultra-high voltage and ultra-high voltage power grids, the insulation oil in transformers, transformers and reactors is extremely demanding. ZJA series oil purifier has super strong dehydration, impurity-removal and harmful gas removal capabilities, and has high safety and stable operation capabilities. The equipment is equipped with first-class vacuum pump system, oil transfer system and filtration system. The filter element with high beta value imported filter material has strong oil particle purification ability. The cleanliness of the filtered oil product is above NAS1638-3, the water content is lower than 3PPM, the gas content is lower than 0.01% (methane and hydrogen Harmful gases such as acetylene are zero), and the breakdown voltage of oil products is greater than 75KV, all oil index fully meet the international UHV requirements. This machine also has the functions of vacuum drying, vacuum oil injection, and hot oil circulation. It can also be used as a separate vacuum pumping unit to the transformer and power equipment.
Features
◆ The vacuum system uses the roots pump as the main pump and the rotary vane vacuum pump as the primary pump. Fast start-up, large pumping speed, stable performance, and high ultimate vacuum of less than 5Pa.
◆ Double horizontal vacuum separators, combined with Duplex-Stereo film evaporation technology
◆ Strong ability to remove impurities: ultra-large area cylindrical precision filter element, with high filtration accuracy, easy installation and replacement.
◆ Low-load heating: Adopt advanced internal and external double-tube heat radiation indirect heating technology.
◆ Automatic control to realize unattended, safe and stable working.
◆ Safety interlock protection for oil pump, vacuum pump, heater to keep safely working
◆ Low noise, easy operation, long maintenance interval, low energy consumption, low operating cost
◆ It can be used together with the insulation oil regeneration device, which has the effect of decoloring, deacidification, deoxidation and removing free carbon and other harmful substances from the oil.
Product Paramenters
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
CHONGQING NAKIN ELECTROMECHANICAL CO.,LTD is joint-stock high-tech enterprise from Chongqing China. We are professional in various oil purifier equipment manufacturing, main products cover vacuum transformer oil purifier, turbine oil treatment, hydraulic oil filtration, waste engine oil regeneration system etc. Since the foundation of our company, we always devote our efforts to produce good quality products. Relying on strong and completely technical supports, advanced producing equipment, perfect quality inspection method, fast and outstanding after-service, our company has developed into a national renowned oil purifier and oil filtration equipment manufacturer in China.
Certifications
Customer Photos
FAQ
Question1. Can you please offer sample?
Answer: Sorry, our products are customized one-to-one according to customer needs, so samples cannot be provided.
Q2. What is your packing method?
A: Generally, our goods packed by wooden box.
Q3. What is your terms of payment?
A: Usually, we use T/T.
Q4. How about your delivery time?
A: Generally, it will take 5 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you customized goods for us?
A: Yes, we can customized by your samples or technical drawings.
Q6. If you have any inspection or test for your goods before delivery?
A: Yes, we do the inspection and test before finished goods.
Q7. Can we visit your factory?
A: Yes, we warmly welcome your visiting, and can pick up you at airport or train station.
