Home > Industrial Equipment & Components > Filtration Equipment & Parts > Air Filter > Wind Power Filter Element DC-2 Reducer Silica Gel Particle Filter DC-3
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
1999
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Gear Box Hygroscopic Filter DC-3 Silica Particulate Respirator Filter ElementNegotiableMOQ: 1 -
China Supplier Desiccant Air Breather Filters Dc-1 Dc-2 Dc-3 Dc-4 Desiccant Breathers For Hydraulic TanksNegotiableMOQ: 1
-
Wind Power Gearbox Desiccant Breather Air Filter Dc-1 Dc-2 Dc-3 Dc-4NegotiableMOQ: 1
-
Desiccant Breather Filter Air Filter Cartridge DC-1 DC-2 DC-3 DC-4NegotiableMOQ: 1
-
Blue Silicone Particles DC-4 Desiccant Air Breather Filter DC-3NegotiableMOQ: 1
Product Description
SINFT Standard Breather Series
PRODUCT SPECS | SFT-SDC-BB | SFT-SDC-1 | SFT-SDC-2 | SFT-SDC-3 | SFT-SDC-4 |
PRICE(USD/pcs) | 12.85 | 14.15 | 17.15 | 22.4 | 26.85 |
Unit Height (in / mm) | 3.90 / 99.06 | 5.31 / 134.9 | 6.125 / 155.6 | 8.125 / 206.4 | 10.125 / 257.2 |
Unit Diameter (in / mm) | 2.52 / 64.1 | 2.52 / 64.1 | 4 / 101.6 | 4 / 101.6 | 4 / 101.6 |
Connection Size | 3/8" Multi-Fit (NPT, BSPP, BSPT) | 3/8" Multi-Fit (NPT, BSPP, BSPT) | 1" Multi-Fit (NPT, BSPT, NPSM) | 1" Multi-Fit (NPT, BSPT, NPSM) | 1" Multi-Fit (NPT, BSPT, NPSM) |
Amount of Silica Gel (lbs / kg) | 0.13 / .058 | 0.28 / .127 | 0.66 / 0.30 | 1.22 / 0.56 | 1.88 / 0.84 |
Adsorption Capacity (fl oz / ml) | 0.79 / 23.3 | 1.68 / 49.7 | 4.00 / 118.2 | 7.45 / 220.3 | 11.3 / 333 |
Max. Flow Rate (cfm) | 4.55 @ 1 psid | 4.16 @ 1 psid | 16 @ 1 psid | 16 @ 1 psid | 16 @ 1 psid |
Max. Flow Rate (lpm) | 128.84 | 117.8 | 453 | 453 | 453 |
Filter Efficiency | 3µ absolute (β₃≥200) | 3µ absolute (β₃≥200) | 3µ absolute (β₃≥200) | 3µ absolute (β₃≥200) | 3µ absolute (β₃≥200) |
Operating Temp. Range (°F) | -20°to 200° | -20°to 200° | -20°to 200° | -20°to 200° | -20°to 200° |
Operating Temp. Range (°C) | -29° to 93° | -29° to 93° | -29° to 93° | -29° to 93° | -29° to 93° |
SIZING / Cross Reference ：
Model | Unit Height(mm) | Unit Width(mm) | Repace Des Case | Replace TTI | Replace XCLUDE |
SFT-SDC-1 | 134.9 | 64.1 | DC-1 | TT-1 | LEXS375-28 |
SFT-SDC-2 | 155.6 | 101.6 | DC-2 | TT-2 | LEXS1-66 |
SFT-SDC-3 | 206.4 | 101.6 | DC-3 | TT-3 | LEXS1-122 |
SFT-SDC-4 | 257.2 | 101.6 | DC-4 | TT-4 | LEXS1-188 |
SFT-SDC-BB | 99.06 | 64.1 | DC-BB | TT-BB | LEXS375-13 |
SINFT VentGuard Series
Gearboxes, reservoirs and pumps all “breathe” in use. As air contracts or expands or as entering fluid displaces air in a system, outside air is drawn in from the atmosphere. Unfortunately, this breathed-in air has water and particulate that will accumulate to contaminate your system.
A desiccant breather is a straightforward solution to the problem, blocking moisture and particles from entering. Testing of leading competitors has shown that Sinft-Dri Desiccant Breathers average almost 20% greater moisture-retention capacity versus leading brands.
Our unique design features a longer body, which permits 10% greater volume of silica gel desiccant beads when compared to leading competitors.
How does SINFT Blue Silica Gel DC Series Desiccant Filter work?
Threaded Mounting Breather Replacement the standard dust cap or OEM breather cap on equipment, offering better filtration to protect against even the smallest particulates that destroy the effectiveness of your machinery, and cause downtime and costly repairs. As air is drawn into equipment through the breather, the layered desiccant filter elements remove particulate while the desiccant beads strip harmful moisture. While in service or during shut-down, the desiccant beads attract moisture from inside the equipment reservoir, actively drying the equipment.
A pink breather means it has done its job keeping moisture out of your lubricants. Time to replace the breather with a new one.
Benefits of SINFT Blue Silica Gel DC Series Desiccant Filter
It can remove the moisture in the head spcae of the equipment efficiently.
It can help prevents sludge deposits, water-contaminated oil, and contamination ingress.
DC-4 Breather can eliminates rust-forming condensation,Provides longer lubricant life, reduces wear and tear on equipment, prolongs life.
It can help prevents sludge deposits, water-contaminated oil, and contamination ingress.
DC-4 Breather can eliminates rust-forming condensation,Provides longer lubricant life, reduces wear and tear on equipment, prolongs life.
Every Filter Element breather Replacement has been designed to work in a wide variety of industries and applications, using quality, rugged materials and innovative designs in technology. As the originator of the first desiccant breather, which has been pioneering the breather industry for years in China. We believe you will love the results you see when using our breathers that we are glad to send you the sample for your first reference.
Application:
For example, a gearbox for wind power generation：
GearboxGearboxes in wind turbines differ from those in high-speed machinery In industrialgearboxes, the progress of failure can occur in weeks, days, or even hours. In windturbines, the impact of contaminants on slower turning gear drives is slow andinsidious. Nevertheless, the mean time between failure(MTBF)for gears andshaft-support bearings can be increased by as much as two to three times by maintaining optimum levels of fluid cleanliness and dryness.
