Hot Sale High Performance Nanocrystalline Core For Common Mode Choke Replacing Ferrite Core

Transformer Ferrite Core Electromagnetic ETD Type

Features:
Material: Mn-Zn
Available materials: Mn-Zn power ferrite and P40/P20//H5K/H7K/H10K/H12K/H15K
Compliant with the RoHS Directive
Customized designs are welcome
High-frequency and low-loss ferrite core
Operating in high frequency
Low loss and high saturation flux density
Good anti-corrosion performance, no need to surface treatment.
Good temperature stability
Good choice for industrial application
All shapes can be customized
Compact crystal
Provide isotropic and anisotropic
OEM service
Short lead time
Compatibility cross series brands ferrite cores
RoHS Directive-compliant

Various types:
EE TYPE CORE -- EE5, EE8.3, EE10, EE12, EE13, EE16, EE16A, EF16, EF16A, EE19, EF20, EE20, EE22, EE25, EF25, EE28, EE28A, EE28B, EE30, EE33, EE35, EE35A, EE40, EE42, EE55, EE65, EE70, EE85, EE120, EE130, EE160, EE220, EE180
EI TYPE CORES EI28, EI33, EI40, EI40B
EP TYPE CORE --EP7, EP10, EP13, EP17, EP20, EP30
EED TYPE CORE -- EED28/20
EER ETD TYPE CORE -- ETD24, ETD29, ETD34, ETD44, ETD49
EFD TYPE CORE -- EFD10, EFD12.5, EFD15, EFD20, EFD25, EFD30
EC TYPE CORE -- EC28, EC35, EC43, EC39, EC54, EC59
EPC TYPE CORE -- EPC13, EPC15, EPC17, EPC19, EPC20, EPC25, EPC27, EPC30, EPC19
PEE PEI TYPE PLANAR CORE --PEE1407, PEE1808, PEE2211, PEE3213, PEE3817, PEE4319, PEE5821, PEE1405, PEI1806, PEI3812, PEI4314, PEI5815
POT TYPE CORE -- P7/4, P9/5, P11/7, P14/8, P18/11, P22/13, P26/16, P30/19, P36/22, P48/30
PQ TYPE CORE -- PQ20/16, PQ20/20, PQ26/20, PQ26/25, PQ32/20, PQ32/30, PQ35/35, PQ40/40 and PQ50/50
RM TYPE CORE -- RM4, RM5, RM6, RM8, RM10, RM12, RM14
UR TYPE CORE -- UR15, UR18.5
UF TYPE CORE -- UF9.8, UF10.5, UF15, UF15.2, UF15.7, UF16, UF17, UF19, UF25, UF30, UF33, UF64, UF65, UF80A, UF80B, UF93, UF96, UF100, UF105A, UF120A, UF120B
UU TYPE CORE -- UU44, UU47, UU64, UU66, UU80, UU93, UU101, UU120, UU126, UU160, UU240 and UU300 series
SNAP-ON FERRITE CORES
Welding rod cores YC/YO Type

Providing quality and standard customer-made electronic and passive components switching transformer and solution products, Fullstar Electronics is a leading switching transformer manufacturer and supplier in China. welcome to wholesale electronics flyback transformer, step-down transformer, high-frequency transformer, audio transformer, SMPS transformer from our factory.

In Cartons

Samples -- in 5 working days
Mass production -- in 4~6 weeks
