Electronic Power and Process Testing Machine Usage 400w dc Electronic Load
- T/T Credit Card
You May Like
Product Description
Electronic Power and Process Testing Machine Usage dc electronic load
|
Model |
PL9610 |
PL9612 |
PL9611 |
||||
|
Channel number |
Single channel |
Two-channel |
Single channel |
||||
|
Input Rating |
Voltage |
150V |
500V |
||||
|
Current |
0~40A |
0~20A |
0~15A |
||||
|
Power |
400W |
400W(2×200W) |
400W |
||||
|
CV Mode |
Range |
0~18V 0~150V |
0~50V 0~500V |
||||
|
Resolution |
1 mV 10 mV |
||||||
|
Accuracy |
±(0.05%+0.025% FS) |
||||||
|
CC Mode |
Range |
0~4A |
0~40A |
0~2A |
0~20A |
0~1.5A |
0~15A |
|
Resolution |
1mA 10mA |
||||||
|
Accuracy |
± ( 0.05% + 0.05%FS ) |
||||||
|
CR Mode |
Range |
0.05Ω~7.5KΩ |
0.1Ω~25KΩ |
||||
|
Resolution |
16 bit |
||||||
|
Accuracy |
0.1% + 0.5%FS |
||||||
|
CP Mode |
Range |
400W |
200W |
400W |
|||
|
Resolution |
10mW |
||||||
|
Accuracy |
0.1% + 0.5%FS |
||||||
|
Dynamic Current |
|||||||
|
Dynamic Mode |
T1&T2 |
100μS~3600S |
|||||
|
Accuracy |
5 μS±100 ppm |
||||||
|
Slope |
0.001~0.15 A/μS |
||||||
|
V Measurement |
Range |
0~18V 0~150V |
0~50V 0~500V |
||||
|
Resolution |
1mV,10mV |
||||||
|
Accuracy |
± ( 0.05% + 0.1%FS ) |
||||||
|
C Measurement |
Range |
0~4A |
0~40A |
0~2A |
0~20A |
0~1.5A |
0~15A |
|
Resolution |
1mA 10mA |
||||||
|
Accuracy |
± ( 0.05% + 0.1%FS ) |
||||||
|
P Measurement |
Range |
400W |
200W |
400W |
|||
|
Resolution |
10mW |
||||||
|
Accuracy |
± ( 0.1% + 0.5%FS ) |
||||||
