Factory direct sale high Quality Powder Coated Commercial Cyclone Fence fence wire mesh

Description of chain link fence:

Chain Link Fences has other names like diamond mesh fences, cyclone fences.The chain link wire mesh is formed by twisting wire raw material together. There are also two kinds of edges which are folded edge and twisted edge. The raw materials can be galvanized steel wire or PVC coated steel wire. The latter one can have custom colors and the most popular one is dark green.

Chain Link Fences are widely used in road, railway and highway fencing projects. And this fencing product is also used for interior decoration, fowl and small animal raising like chickens, ducks, geese, rabbits and also zoo fencing projects. Other scenarios using Chain Link Fences are machinery and equipment protection, sports venues, green belt. Sometimes people use Chain Link Fences as gabions by forming a box shape with it and filling it with stones. It can also be used for the protection and support of seawalls, hills, bridges and reservoirs, and other civil works. It is a great material for flood control. Besides, Chain Link Fences can also be used for handicraft material, warehouses protection, cold storage protection and building site protection, and so on.

As you can see, Chain Link Fences really does a great job for so many fencing scenarios. It’s cost-effective and quite good-looking. It’s an pretty ideal fencing choice for everybody.

NOTES:

Height: the height of the chain link fence.
Width: the distance between two chain link fence posts, measure from center to center.
Wire Thickness: the diameter of the chain link fences wire after PVC coated.
Mesh Size: the edge length of the mesh
Flat Bar: a flat bar for making chain link mesh straight in vertical.
Post Cap: a small tool for covering on top of the post, in order to prevent the rain fall in to the post
Pre Hot Dipped Galvanized: the wire material already been hot dipped galvanized before producing the chain link fences. The zinc layer of pre – hot dipped galvanized is lower than hot dipped galvanized.
Electric Galvanized + PVC Coated: electric galvanized (zinc coating 8~12g) as a pre – surface treatment inside, then use PVC coated layer outside to prevent the chain link fences from getting rusty.

Introduction of Galvanized Chain Link Fence Specifications
The chain link fence is a rather complex fence product compared with other fences. Though it seems very simple, with weave wire and post, it seems that’s all of the parts it has. But if you observe this style of fence carefully, you may catch the difference.
Then, let me have a detail introduction of the galvanized chain link fence specifications to you and show you the galvanized chain link fence specifications.
Chain link fence usually consist of weave wire, strength post, line post, flat bar, clamp, post cap, tie wire, tension wire, tension machine, round band or screw band. If else need, the prop, branch arm are also one of the constituent part. Next, i’ll emphasize the specification of the weave wire, post and some of the accessories for you.
The galvanized chain link fence specifications is consist with the galvanized wire which thickness is selectable from 2.5mm to 5.0mm. With the wire twisty, through rotate adjacent wire, the wire fence is complete. Same with the other fence, then chain link fence’s height and width are changeable as your requirements.
And the galvanized chain link fence specifications shows next. Usually the height is between 1200mm and 2200mm, and the width is between 2000mm and 15000mm. To support the wire fence, there’s post needed. With round post differ from dia 42mm to 75mm, the post can support the wire fence upright. In a general way, we put two strength post to the each side of the wire fence, and several line post in the middle of the chain link fence, about 3m/pcs.
The line post is a little thinner than the strength post. As for the surface treatment, it’s all depends on your hobby. If you want silver color, the galvanized chain link fence is your best choice. With the zinc coating mass 100-280g/m2, you can choose with your budget and expected life.

Products Show:
