Solar Panel 540w Mono Cell Watt Power Energy Monocrystalline Aluminium Frame
US$ 0.27 - 0.28
MOQ: 10000 Wp
Key Specifications
Get Latest Price
Brand Name:
ZONERGY
Place of Origin:
China
Model Number:
ZPM525~545MH5-72
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
7 days
Related Products
-
ZONERGY 445 W 445w Solar Cells Panel Energy Monocrystalline Mono Power Oem PriceUS$ 0.23 - 0.25MOQ: 10000 -
Zonergy 450w Perc Solar Panel Cells Energy Monocrystalline Mono Power Oem PriceUS$ 0.27 - 0.28MOQ: 10000
-
Zonergy 480w 485w 490w 495w 500w 505w Solar Cells Panel Monocrystalline Mono Power Oem PriceUS$ 0.27 - 0.28MOQ: 10000
-
Zonergy 525w 530w 535w 540w 545w 550w Solar Cells Panel Monocrystalline Mono Power Oem PriceUS$ 0.27 - 0.28MOQ: 10000
-
Zonergy 580w 585w 590w 595w 600w Solar Cells Panel Monocrystalline Mono Power Oem PriceUS$ 0.27 - 0.28MOQ: 10000
Brand Name
ZONERGY
Place of Origin
China
Model Number
ZPM525~545MH5-72
Material
Monocrystalline Silicon
Size
2279x 1134 x35mm
Max. Power
545
Number of Cells
144 (6×24)
Technology
What is a half cell?
Half-cell technology is a technique of laser cutting a standard size cell (156 mm x 156 mm) equally into two cells (156 x 78 mm), which are cut and connected together. The cells of the entire module are then divided into two groups, each containing 60 half-cells connected in series, and the cells form a complete 120-cell module, thus reducing the current through each main grid to 1/2 of the original, and reducing internal losses to 1/4 of the whole cell, thus increasing the module power.
1.Higher Yield Due to Better Shading Response
Half Cell Module comprises two separated and identical solalr cell arrays, which means the ordinary strings of cells are cut into halves, and these shorter strings compose which has separated current paths. When a module is shaded, only one side shaded array's current will be impacted, while the other array will still be functionally producing power. Under this circumstance, when a module is shaded, the affected working areas of Blade will be 50% less.
By cutting solar cell into halves, the internal power loss will be lower and hot spot effect will also be reduced.
Instead of 6 internal strings of cells, half cell module has 2*6 shorter ones. This design effectively deals with the mismatch happened between cells caused by shadow, out of sync performance degradation, etc.
SYSTEM & PRODUCT CERTIFICATES·IEC 61215 /IEC 61730/IEC 61701/IEC 62716
ISO 9001: 2015 Quality Management System
ISO 14001: 2015 Environment Management System
ISO 45001: 2018 Occupational Health and Safety Management Systems
ISO 9001: 2015 Quality Management System
ISO 14001: 2015 Environment Management System
ISO 45001: 2018 Occupational Health and Safety Management Systems
| ZPM525~ 545MH5-72 Half-Cell Monocrystalline Silicon PV Modules Mechanical Data | |
| Cell Type | 182×91mm Mono |
| Cell Orientation | 144 (6×24) |
| Module Dimensions | 2279x 1134 x35mm |
| Weight | 29.0kg |
| Glass | 3.2mm high transmittance, reinforced glass |
| Backsheet | Anti-aging film |
| Frame Material | Anodized aluminum alloy |
| Junction Box | Protection class IP68 |
| Cable | 4.0 mm2 positive pole: 300 mm negative pole: 400 mmwire length can be customized |
| Connector | MC4 compatible connector |
| I-V Curve | Electrical Data (STC) | |||||
|
Current-Voltage Curve(455W)
|
Maximum Power (Pmax/W) | 525 | 530 | 535 | 540 | 545 |
| Voltage at Maximum Power (Vmp/v) | 40.58 | 40.73 | 40.88 | 41.03 | 41.18 | |
| Current at Maximum Power (Imp/A) | 12.95 | 13.02 | 13.10 | 13.17 | 13.24 | |
| Open Circuit Voltage (Voc/M) | 49.08 | 49.23 | 49.38 | 49. 53 | 49 68 | |
| Short Circuit Current (Isc/A) | 13.39 | 13.46 | 13.54 | 13.63 | 13.71 | |
| Module Efficiency (%) | 20.31 | 20.51 | 20.71 | 20.89 | 21.09 | |
| STC(Standard Testing Conditions): lrradiance 1000W/m2, Cell Temperature 25*C,AM1.5 | ||||||
|
Power-Voltage Curve(455W)
|
Electrical Data (NMOT) | |||||
| Maximum Power (Pmax/w) | 392 | 396 | 400 | 404 | 408 | |
| Voltage at Maximum Power (Vmp/M) | 37.34 | 37.49 | 37.64 | 37.79 | 37.94 | |
| Current at Maximum Power (Imp/A) | 10.51 | 10.57 | 10.64 | 10.70 | 10.77 | |
| Open Circuit Voltage (Voc/V) | 45.11 | 45.26 | 45.41 | 45.56 | 45.71 | |
| Short Circuit Current (Isc/A) | 11.14 | 11.22 | 11.29 | 11.37 | 11.44 | |
| NMOT (Nominal Moudule Operating Temperature): Iradiance 800W/m , Ambient Temperature 20'C,AM1.5, Wind Speed 1m/s. | ||||||
| Temperature Coefficients | Operating Parameters | ||
| Temperature Coefficient(Pm) | -0.350%℃ | Maximum System voltage | 1000/1500v |
| Temperature Coefficient(Voc) | -0.270%℃ | Operating Temperature | -40℃~+85℃ |
| Temperature Coefficient(Isc) | -0.048%℃ | NMOT (Nominal MouduleOperating Temperature) | 41+3℃ |
| Packaging | |||
| Modules Per Pallet | 31+31pcs | Modules Per 40'HQ Container | 620pcs |
