Luxing Simple Cover Rectangle Rail Machinery Cnc Milling XK7136 Universal Cnc Milling Machine 3axis 4 Axis Machining Center
Luxing simple cover rectangle rail machinery cnc milling XK7136 universal cnc milling machine 3axis 4 axis machining center
Machine main specifications:
|
Specifications
|
Units
|
XK7126
|
XK7136
|
|
Table size
|
mm
|
1000x260
|
1250x360
|
|
X axis travel
|
mm
|
500
|
900
|
|
Y axis travel
|
mm
|
330
|
400
|
|
Z axis travel
|
mm
|
450
|
500
|
|
Max. worktable load
|
kg
|
300
|
400
|
|
T slot(number-width-pitch)
|
3-14
|
3-18
|
|
|
Max. spindle speed
|
rpm
|
8000
|
8000
|
|
Spindle taper
|
mm
|
BT40
|
BT40
|
|
Main motor power
|
kw
|
3.7
|
5.5
|
|
X/Y/Z rapid traverse speed
|
m/min
|
10/10/8
|
10/12/10
|
|
Cutting feed speed
|
mm/min
|
1-4000
|
1-6000
|
|
Guide rail type
|
Box guide (rectangualr)rail
|
Box guide (rectangualr)rail
|
|
|
Distance from spindle axis to column surface
|
mm
|
390
|
460
|
|
Distance between spindle nose and worktable surface
|
mm
|
100-550
|
100-600
|
|
Positioning accuracy
|
mm
|
0.01
|
±0.015
|
|
Repeat positioning accuracy
|
mm
|
0.01
|
±0.008
|
|
Tool changer
|
Optional
|
Optional
|
|
|
Machine weight
|
kg
|
2000
|
3500
|
|
Overall dimension
|
mm
|
1600x1600x2100
|
2380x1900x2350
|
Details:
1:How can I choose the most suitable machines?
A: Please tell me your specifications (or send your workpiece drawing to us) ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Band Saw Machine ,Shaper machine and so on .
3: How long is the delivery time?
For standard machines,it would be around 30 days;For non-standard machines and customized machine according to client’s specifications requirements,it wouble be a little longer.
4.Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277599 China.
You are warmly welcomed to visit us.
5. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
6: What's the Payment Terms?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
