Closed type ear tag surgical instruments plastic and metal 20W fiber laser marking machine
Skype: lingxiangcnc12 Tel/whatsapp:+8613165141706 Email: export12(@)
| Working area: | 70*70mm-300*300mm for optional |
| Application materials: |
1) Many type of metals |
| Application industries |
1)Sports Equipment 2)Precision & General Engineering 3)Automotive 4)Domestic Appliances 5)Promotions & Giftware 6)Medical 7)Machine Cutting Tools 8)Electronic Devices |
Machine appearance display:
Machine basic configuration:
#Laser generator 20W
#Table: 2D Aluminum alloy up-down table
#Field Lens
#galvanometric scanning system from Beijing Century company
#Control system:PC control system
#Beijing JCZ card board and EZCAD
#Graphic format: BMP,JPG,GIF,PNG,AI,DXF,DST,PLT,etc
#Support interface: all-English language ,Chinese,Japanese and Korean
Machine specific parameter:
|
Technical parameters of fiber marking machine |
|
|
Product name |
Fiber laser marking machine |
|
Power |
20w/ 30w/ 50w (optional) |
|
Laser source |
MAX, RAYCUS, IPG ( optional) |
|
Working area |
150*150mm, 200*200mm, 300*300mm (optional) |
|
Laser wave length |
1064nm |
|
Marking depth |
≤1.2mm |
|
Marking Speed |
800 standard characters/second |
|
Minimum Line Width |
0.012mm |
|
Minimum Character |
0.15mm |
|
Repeated Perecision |
±0.003mm |
|
Life-span of fiber laser module |
100 000 hours |
|
Beam Quality |
M2 <1.5 |
|
Focus Spot Diameter |
<0.01mm |
|
Output Power of Laser |
10%~100% continuously to be adjusted |
|
System Operation Environment |
Windows XP / W7--32/64bits / W8--32/64bits |
|
Cooling mode |
Air-cooling-Built-in |
|
Temperature of Operation Environment |
15℃~35℃ |
|
Power input |
220V / 50HZ / single phase or 110V / 60HZ / single phase |
|
Power Requirement |
<1000W |
|
Communication Interface |
USB |
|
Optional device |
Rotary device, External red light pointer, goggle, floodlight |
Machine features:
Machine samples:
1.Our wooden case is after fumigation treatment.Needn’t timber inspection,saving shipping time.
2.All the spare parts of the machine were covered by some soft materials,mainly using pearl
wool.Avoiding all damages that could happen in the delivery process.Then we’ll covered plastic wrap out it tightly,make sure intact of the covered soft materials,also avoiding Waterproof
and rust proof.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.
Customer feedback:
1. I want to buy this machine,what suggestion can you give?
Please tell me:what material do you process? What's the size of your material?(Better show me your product picture)
2. What is the machine standard voltage?Can change to 110V?
The machine Standard voltage is220V,50HZ or 60HZ .We can change to 110v 50HZ or 60HZ.Need add 150USD.
3. 20W 30W 50W There are other differences besides the power difference?
1) The marking depth is proportional to the laser power.
2) Marking speed: The greater the power, the greater the speed.
4. Q: What language the software support?
A: Chinese, English, Japanese, and Korean.
Also we can custom-made with Russian language, price add 200USD.
Skype: lingxiangcnc12 Tel/whatsapp:+8613165141706 Email: export12(@)
