Beifang CR Injector Machine Lift Measurement Tools Diesel Injection Measuring Repair Tool
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Common Rail Injector Valve Measuring Tool Common Rail Injector Stroking Measure Tool
-
Diesel Fuel Injector 0445120078( 0 445 120 078)
-
CUMMI'NS DISMOUTING TOOLS FOR EUI N14 L10 REPAIR TOOLS
-
VOLVO' EUI Dismounting Tool VOLVO' EUI Repair Tools for VOLVO' 20430583 20440388 20500620
-
CUMMI'NS EUI N14 L10 DISMOUTING REPAIR TOOLS N14 L10 Repair Tools
-
VOLVO' EUI Assembling and Disassembling Tools EUI Repair Tools VOLVO' EUI Dismounting Tool
Product Description
Product Overview
Common rail injector measuring tools suitcase
Common rail injector measurement tools is used to test the travel range for shims or valve adjusting. It is the helpful tools for you to check injector inside parts. used on CRIN1,CRIN2,CRI, and densso G2 injectors.
FEATURES AT A GLANCE
COMPACT DIMENSIONS
EXTENDING UNDERCARRIAGE
SAFETY FRAME
SIMPLE CONTROL
SEASY MAINTENANCE
VERSATILITY
EXTENDING UNDERCARRIAGE
Right elevation
Left elevation
Front elevation
Function
1.Test nozzle pin valve lift, which decides nozzle pin valve shim thickness (Horsepower different)
2.Test armature total range, which decides circlip thickness
3.Test armature range, which decides the hexagonal shim thickness below.
4.Test remaining air gap, which decides the hexagonal shim thickness above.
5.If VE is not proper, pls debug solenoid valve spring force adjusting shim.
6.If LL is not proper, pls debug nozzle pin valve spring force shim.
2.Test armature total range, which decides circlip thickness
3.Test armature range, which decides the hexagonal shim thickness below.
4.Test remaining air gap, which decides the hexagonal shim thickness above.
5.If VE is not proper, pls debug solenoid valve spring force adjusting shim.
6.If LL is not proper, pls debug nozzle pin valve spring force shim.
Technical Parameters
1 | Armature lift test | 45-50um |
2 | Cross lift test | 30-50um |
3 | Remainin air gap test | 35-55um |
4 | Armature total range | 50-70um |
5 | Test injector model | common rail solenoid injector Bos ch Dens o |
Company Introduction
Taian North Test Equipment Factory founded in 2003. It is the top manufacturer of diesel fuel injection system testing equipmentand diagnostic tools in China. It is also one of the first factories in mainland China to develop and manufacture diesel fuelinjection system testing equipment and diagnostic tools.
