Help CenterLightweight Precast Concrete Wall Panel Machine for Prefab House
Related Products
-
Precast Concrete Wall Panel Making Machine/ Machine to Produce Wall PanelUS$ 150 - 10,000MOQ: 1 Set -
Ceiling Tile Making Machine / PVC Laminated Gypsum Tiles Manufacturing Machine LineUS$ 29,000 - 160,000MOQ: 1 Set
-
Construction Buildings Pvc Ceiling Tiles Gypsum Board Laminating Making MachineUS$ 29,000 - 160,000MOQ: 1 Set
-
30,000ton /year -400,000ton/year Hot Air Boiling Furnace Technology Gypsum Powder Making Production LineUS$ 60,000 - 60,000MOQ: 1 Set
-
Sand /fly Ash Cement Concrete Lightweight Interior Wall Panel Making MachineUS$ 50,000 - 500,000MOQ: 1 Set
Our company is specialized in designing and manufacturing lightweight wall panel production line. With 17 years' experience in wall panel machine, has more than 60 projects in domestic and foreign markets.
Eps lightweight wall panel machine is designed to adapt to the recent development trend of building materials. The material is made of cement and foam material. It has light weight features and has a large volume of demand in the market. Our company has boldly designed this highly automated production line.
Our unique design that can be fully automatically remolded with 10 panels/time. This can save a lot of labor costs.
demoulding, 20panels/time. So can save a lot of your labor cost
Machinery Parameters | ||
Capacity | 20,000sqm~600,000sqm per year | |
Thickness | 50-250mm thickness. special sizes need to be customized | |
Length | 2440~3600mm, special sizes need to be customized | |
Width | 610mm , special sizes need to be customized | |
Raw material | There are mainly two different types 1. Cement+fly ash/eps/ceramsite/sand, etc (optional, can choose to add or not add) 2. Formed cement+additives | |
Finished board Types | 1. Composite board/sandwich board, with surface board 2. Lightweight solid panel, without surface board | |
Surface board types | 1. Calcium silicate board 2. Fiber cement board 3. MgO board | |
Material | EPS, cement, water, sand, flyash | |
Advantages | Higher automatical, save labor cost, good market | |
Raw materials mix
Name: Mixing platform
Advantage: Double shaft, automatic metering machine.
Double shaft mixer could mix the materials more even, auto metering could make sure the formula is stable and accurate.
We adopt double-shaft mixer, which has a compact structure, beautiful appearance, stable running, convenient operation, high production efficiency.
Machine Parts
Name: Pumping system
Brand: Patented
Used to paste into the mold can avoid the air holes.
The feeding machine can be movable, or fixed, matched well with the mold car, easily operate
Mould Car
Name: Mould car
Advantage: Different type could suit for different requirements
Automatic open mold, automatic unloading board, automatic flip demolding.
After curing, unloading the wall panel and stacking. our unique advantages, full automatic unload the panel 20 panels per times.
