More than 5 Years Warranty and Automatic Grade chemical materials mgo board production line

The factory is not only NO 1 in configuration ,but also automatic degree in China .

We are building material group company with 8 branches specialized in different building material and machinery manufacturing with 30 years history. our company occupy the finest mgo board production ,formular and the highest configuration machinery equipment in china .

 Raw material feeding and metering automatic

For the mixtures,we totally have 5 mixers, the first slurry materials mixer and second is the

sanding materials mixer.And the rest part is 3 middle layer mixers .Why we equip 3 middle

layer mixers ? it is because for the mgo board the main part is middle layer materials when

we produce every thick mgo board for example mgo board above 18 mm then if we equip the

 3 mixers middle layer mixer. It will be much more easier and high efficiency during the

production.The mixers are double shaft so it can keep raw materials mixer very evenly .

Double shaft mixer

Using unique double shaft mixer,ensuring mixing evenly and no blocking.

Each mixer has a dust collector,and the material is automatically connected to the mixer to avoid dust.

Automatic forming part

This part is mainly production part, we use sucker to suck the PVC mold on the machine.This

 part is release agent. After we put release agent on the PVC mold, it will be very easy to

separate the PVC mold with the board-mgo board. The first layer is slurry materials after the

slurry material there will be two layer mesh, this is middle material and then another 2 layers

 mesh.You can see,we equiped to several fiber glass mesh rollers.It is because some

customers have special requirement on the bending-strength of the mgo board. So we need

to put more layers fiber glass mesh in the board.

Automatic cutting machine

Equirement function and characteristics :Exactly cutting the board into designated

specification during production flow,no damage to the products and moulds,reducing labor

cost and lower working strength .Consists of rack,cutting walking frame,cutting

saw,clamping part,open sections,length part,electrical control system ect.

Full automatic mould releasing

Automatically stack board board together,automatically cleaning and curing the used mold,automatically stracking mold for stand-by.

Here i share with you the mgo board production process video, which could make you have a clear understanding about how this machine works. https://youtu.be/-tBHxhdW4fc
