CE Guangzhou Chemical Laboratory Used All Steel Laboratory Fume Hood

Model

BK-WFH-003

Size (standard)

2400(W)*950(D)*2350(H)mm

3000(W)*950(D)*2350(H) mm

3600(W)*950(D)*2350 (H) mm

Customized size acceptable

Material

Industrial Ceramic/Epoxy Resin/Laminate/Stainless Steel

Color

White/blue/customized

Worktop

Equipped with phenolic resin, epoxy resin, stainless steel board or ceramics to meet your specific needs

Sash

The sash slides smoothly in a horizontal manner. It is made of at least 6mm thick clear tempered glass to protect the user while providing excellent visibility.

Inner Liner

Constructed from compact laminate, it is a high temperature and high pressure decorative plates, water proof, resistant to moisture, impact, abrasion, acid corrosion, and heat resistance, it can prevent the accumulation of contaminants and keep gas, mist flow discharge.

Control Panel

Used to control the start and stop of the fume hood, LCD display, can be manually controlled to fan, light and volume.

Cabinet

It is frame structure under the detoxification cabinet which can allow the operator to have free space for desired short cabinet to be located within.

Sink Cup

Imported PP integrate molded sink with acid and alkali resistance

Faucet

The water faucet nozzles are made of high quality copper and coated in epoxy resin powder,water faucets are specially designed for use in labs. Subject to change accordingly with customer’s desires

Steel Finish

Environmentally friendly, electronically applied powder coat finish

Accessories

1.Modular electric sockets panel and control devices

2.Removable painted metal plugging (outside)

3.Two tubes fluorescent lamp (LED on request)
