RC-100 Dead Weight Creep Rupture tester
Applications:
This creep tester is designed and built for testing the creep properties and creep rupture strength on ferrous metal, nonferrous metal and their alloy that subjects to constant tensile load at a certain temperature at the specified time interval. It is designed according to “ high temperature creep & rupture strength GB/2039-1997” National Standard. Meanwhile, it conforms to ISO204/1997 International Standard and HB5151-96 Aviation Industrial Standard. It can offer liable test/inspection certificate for aviation Industry & other special materials property that should endure high temperature.
Specification:
1.Capacity: 100KN
2.Load range: 2-100% FS
3.Load accuracy: ≤±1.0%
4.Variation of indicating load value: ≤±1.0%
5.The eccentricity of the upper and lower chucks: ≤10%
6.Min dead weight load: 1N
7.Automatic level range: ±0.1mm
8.Lever ratio: 1:50 / 1:100
9.Lower tensile rod speed: 0-50mm/min
10.Lower tensile rod stroke: 0-200mm
High temperature furnace & Temperature-controller
Working Temp. range: 400°C~1200°C
Length of effective soaking zone: 150mm
Furnace pipe & electric furnace size:
Furnace pipe: φ90mm (Inner Dia.)×400mm (L),
Furnace: φ300mm (outer Dia,)×420mm (L);
Furnace life: ≥3000hours (Constant working time less than 1000°C)
Furnace Temperature accuracy (°C):
Test Temperature | Temperature fluctuation | Temperature gradient |
≤600 | ±2 | 2 |
>600~900 | ±3 | 3 |
>900~1200 | ±4 | 4 |
Measure & Control temperature meter: digital display, sensitivity: 0.1°C;
Auto compensation error of cold end:≤0.5°C;
To be matched freely with thermocouple.
Moving speed of lower grip holder
Speed range: 0.005~50mm/min;
Error: ±0.5%
Timing error: ±0.2%
Structure:
This testing machine consists of main unit, heating furnace, temperature measuring system, and deformation measuring system. The main unit & heating furnace forms a complete set in applications. Temperature measuring system adopts group control & centralized administration. Deformation measuring system features as centralized checking, auto recording & random looking over history test data.
1. Inner package: dust-proof plastic bag
2. Outer package: standard export wooden case with pallet
3. Special packages: according to buyer's requirements
4. The packages suitable for international transport by sea, by air or any other delivery methods
OUR COMPANY-JINAN PRECISION TESTING EQUIPMENMT CO.,LTD (PTE)
PTE- A Material Testing Machine Manufacturer
About PTE
JINAN PRECISION TESTING EQUIPMENT CO., LTD is one of the top-ranking manufacturers and suppliers of testing technologies worldwide. With many years experience in this filed, we can supply standard and customized solutions for many test, measurement and quality control tasks required in the world of modern materials testing.
The main products from JINAN PRECISION TESTING EQUIPMENT include universal testing machines, Sample preparation equipment, non-metal materials testing equipment, spectrophotometer, Temperature Chamber, which can used for testing metals, plastics, rubber, textiles, paper, paint, cement, concrete and packaging materials, etc. Their usage is very wide.
Welcome to enquiry and prompt reply will be done by our professional technical and sales person.
1. Pre-service
--24 Hours online service for your consult.
--Help choose right model,and a series of service,person,advise.
2. Middle service
--Give you best offer
--Provide discount for many sets order
--Do customer's request:
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
3. After sale service
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Remote control technical consult
--Free installation DVD
--Maintenance plan
For more products:
WAW-C Hydraulic unviersal testing machine
| Model | WE-100C |
| Max. Testing Load (kN) | 100 |
Load range(kN) and Min | 0-20/0.05 |
Max. tensile space | 560 |
Max. Compression space | 530 |
Max. Distance Between Two | 400 |
-------------------------------------------------------------------------------------------------------------------------------------------------------
Compressive strength testing machine for concrete
| Model | YES-1000 |
| Load display accuracy | ±1% |
Distance between upper | 320mm |
| Diameter of lower platen | 300 mm |
| Piston stroke | 30mm |
| Pump nominated pressure | 40MPa |
-------------------------------------------------------------------------------------------------------------------------------------------------------
Strength testing machine (single column):
| Model | WDW-E1,E2, E3, E5, E10, E20, E30, E50, E100 |
| Max. Load | 1kN,2kN,3kN,5kN,10kN,20kN |
| Deformation accuracy | ≤±0.5% |
| Load speed | 0.005-500mm/min |
| Total crosshead travel (mm) | 1075 |
| Spacing of grip to grip(mm) | 750 |
-------------------------------------------------------------------------------------------------------------------------------------------------------
PLG 300C PC Control High Frequency Fatigue Testing Machine
| Model | PLG-10C PLG-20C PLG-50C PLG-100C PLG-200C PLG-300C |
| Mean load max(kN) | ±10 .... |
| Load step | 1,2,5 |
| Accuracy of static load | ≤±1% |
| Range of frequency(Hz) | 60~300HZ |
| Power | 380V, 3phs, |
-------------------------------------------------------------------------------------------------------------------------
WAW Computer Control Servo Hydraulic Universal Testing Machine
| Model | WAW-300E WAW-600E WAW-1000E WAW-2000E |
| Max. Testing Load (kN) | 300 .... |
| Load Accuracy | ≤±1% from 2% to 100% of full scale |
| Strain accuracy | ≤±0.5% |
| Load frame Type | 4-column and 2-screw structure |
| Max. tensile space (Including piston | 690 |
-------------------------------------------------------------------------------------------------------------------------------------------------------
TORSION TESTING MACHINE
| Item | NJS-30 |
| Max torque(Nm) | 30 |
| Torque resolution (Nm) | 0.01 |
| Accurate measuring range of torsion (Nm) | 0.6-30 |
| Full-scale reading of torsion angle (º) | 9999.9 |
| Torsion angle resolution (º) | 0.01 |
-------------------------------------------------------------------------------------------------------------------------------------------------------
PLS Dyanmic testing machine
| Model | PLS-50 |
| Static | ±50 |
| Dynamic | 50 |
| Function generator Range of frequency(Hz) | 0.01~20HZ |
| Stroke of piston(mm) | ±75 |
| Distance between columns | 500 |
RTH CREEP TESTING MACHINE
| Working Temp. range | 400°C~1200°C |
| Length of effective soaking zone | 150mm |
| Furnace pipe: | φ90mm |
| Furnace: | φ300mm |
| Furnace life: | ≥3000hours |
| Timing error | ±0.2% |
