11 Holes pp Sheet Protect File Making Machine
US$ 5,000 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
XH
Place of Origin:
Zhejiang, China
Model Number:
NYJ-500A
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PP Sheet Extruder For Plastic Cup,File FolderUS$ 40,000 - 46,000MOQ: 1 Set -
New Sock Machine Made in ChinaUS$ 5,000 - 10,000MOQ: 1 Set
-
New Sock MachineUS$ 5,000 - 10,000MOQ: 1 Set
-
2014 New Automatic Machine for Plastic Cup,spoon,knife and Fork,etcUS$ 5,000 - 10,000MOQ: 1 Set
-
Nespresso Compatible Capsules Coffee Filling and Sealing Machine Made in ChinaUS$ 15,000 - 20,000MOQ: 1 Set
Brand Name
XH
Place of Origin
Zhejiang, China
Model Number
NYJ-500A
Condition
New
This machine is suitable for making PP 11 hole data pocket and general inner data bag.
Usage: 11 hole data pocket and general inner data bag.
Main technical parameters:
- Max width of bagging: 500mm
- Max length of bagging: 310-500mm
- Thickness of PP film: 0.03-0.1mm
- Speed of bagging: 110pcs/min
- Power required: 7.5kw
- Overall dimension: 6500×1500×1500mm
Process:
- There is an unwinding cradle which is used for loading PP tube film, openning device to ultrasonic for sealing, before sealing, there is an insert white stripe device, puncher to cut off and then through the belt transimission the final product to the bedplate.
- Main control: It adopts the MITSUBISHI PLC programmable logic controller as main control, YASKAWA AC servo motor and touch screen.
- This machine has knurling, pneumatic puncher, auto following feeding and auto deviation correcting device, etc.
- It is the necessary machine which is used for stationery industry.
