HAS Video Sticker Label Die Cutting Machine From Roll to Sheet or to Roll With Hot Stamping,hole Puncher

HAS Video Sticker Label Die Cutting Machine From Roll to Sheet or to Roll With Hot Stamping,hole Puncher photo-1
HAS Video Sticker Label Die Cutting Machine From Roll to Sheet or to Roll With Hot Stamping,hole Puncher photo-2
HAS Video Sticker Label Die Cutting Machine From Roll to Sheet or to Roll With Hot Stamping,hole Puncher photo-3
HAS Video Sticker Label Die Cutting Machine From Roll to Sheet or to Roll With Hot Stamping,hole Puncher photo-4
HAS Video Sticker Label Die Cutting Machine From Roll to Sheet or to Roll With Hot Stamping,hole Puncher photo-5
HAS Video Sticker Label Die Cutting Machine From Roll to Sheet or to Roll With Hot Stamping,hole Puncher photo-6
US$ 9,000 - 12,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
XIAO HAI
Place of Origin:
Zhejiang, China
Certification:
ISO9001:2008
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Brand Name XIAO HAI
Place of Origin Zhejiang, China
Certification ISO9001:2008
Type Die-cutting Machine
Warranty 1 Year
Weight 1000kg
Dimension(L*W*H) 2800x1100x1600mm
Condition New
Voltage 220V/380V
Computerized Yes

sticker Label die cutting machine from roll to sheet or to roll with hot stamping,hole puncher

 HAS Video Sticker Label Die Cutting Machine from Roll to Sheet or to Roll with Hot Stamping,hole PuncherHAS Video Sticker Label Die Cutting Machine from Roll to Sheet or to Roll with Hot Stamping,hole PuncherHAS Video Sticker Label Die Cutting Machine from Roll to Sheet or to Roll with Hot Stamping,hole PuncherHAS Video Sticker Label Die Cutting Machine from Roll to Sheet or to Roll with Hot Stamping,hole PuncherHAS Video Sticker Label Die Cutting Machine from Roll to Sheet or to Roll with Hot Stamping,hole Puncher





Usage:
1.
It is used for cutting the plastic label on the electronic products and all kinds of adhesive tapes.

2.This machine adopts flat to flat platen,high accurate mould die cutting,label conveyor and sheeting controlled by micro-computer and touch screen ,two side of printed mark and longitudinal direction tracked by three photoelectric cell(web guide).Die cutting,rewind waste paper, sheeting can finish at one time.This machine and label slitter is necessary auxiliary machine for the flexo printing machine or continuous screen printing machine.



Product Description



Model:

320model

420model

Die cutting speed:

20-125t/min

20-125t/min

Max. releasing diameter:

450mm

450mm

Max. roll paper width:

320mm

420mm

Max. die cutting width:

300mm

400mm

Max. die cutting length:

290mm

400mm

Positioning precision:

±0.15mm

±0.1mm

Gross power:

3kw

4.5kw

Power supply voltage:

220v±10%

380v

Whole machine weight:

about1500kg

about2300kg

Overall dimensions:

2.6(L)x0.95(W)x1.4(H)(m)

2.7(L)x1.05(W)x1.5(H)(m)
