Home > Products > Material testing machine > T-BOTA TBTUTM-1000B LCD Good Stable Quality Digital Display Hydraulic Universal Tensile Testing Machine
T-BOTA TBTUTM-1000B LCD Good Stable Quality Digital Display Hydraulic Universal Tensile Testing Machine
- ShangHai or other China Port
- T/T Credit Card
You May Like
-
TBTUTM-1000B LCD Digital Display Universal Testing Machine
-
T-BOTA Electronic Universal Testing Machine + Tensile Testing Machine Price+Lab Equipment Price
-
T-BOTA 10kN 20kN 50kN 100kN 200kN 300kN Computer Universal Tensile Strength Testing Machine
-
T-BOTA Bone Type Concrete Sample UTM Universal Testing Machine TBTWDW-30/50 Universal Concrete Tensile Strength Tester
-
T-BOTA Electronic TBTWDW-20KN Universal Testing Machine for Plastic Film Tensile Strength Measurement by Digital Display
-
T-BOTA Digital Display Electromechanical Terminals Wire Plastic Film Tensile Machine Universal Testing Machine
Product Details
| Brand Name | TBT | Place of Origin | Jiangsu, China | |
| Model Number | TBTUTM-1000B | Power | Hydraulic |
Product Description
Universal Testing Machine with LCD screen digital display
The testing machine is mainly designed for metal of tension test, compression test and bending test, also for non-metal of compression test, such as concrete and stone. If the proper jigs are provided, it can be used for various tests in the laboratories of mills, factories, colleges and research units concerned.
It is featured with hydraulic loading, electronic force measurement, the load, displacement and loading speed display, peak force value maintained, overload protection and test data protection when the power supply is cut off temporarily. The test data can be processed automatically and printed out.
Technical Specification
|
Model |
WA-100B |
WA-300B |
WA-600B |
WA-1000B |
|
Max. Capacity(KN) |
100 |
300 |
600 |
1000 |
|
Range |
4%-100%F.S.(Full range, without gear) |
|||
|
Reading accuracy |
Grade 1 |
|||
|
Error |
±1% |
|||
|
Column Number |
4 |
4 |
4 |
6 |
|
Width between two column |
345 |
430 |
515 |
510 |
|
Max tensile space(mm) |
500 |
600 |
600 |
600 |
|
Max compression space(mm) |
500 |
600 |
600 |
600 |
|
Bending test Distance between two points (mm) |
100-270 |
100-350 |
100-400 |
100-400 |
|
Round specimen clamp diameter(mm) |
Ø6-Ø22 |
Ø10-Ø32 |
Ø13-Ø40 |
Ø20-Ø40 |
|
Flat specimen clamp thickness (mm) |
0-15 |
0-15 |
0-15 |
0-40 |
|
Stroke (mm) |
150 |
200 |
||
|
Pistons rise fastest speed(mm/min) |
100 |
80 |
||
|
Beam rising speed (mm/min) |
310 |
250 |
250 |
310 |
|
Displacement reading relative error |
±1% |
|||
|
Motor capacity (KW) |
2 |
2.5 |
||
|
Main unit dimension (mm) |
665×490×1600 |
740×460×1900 |
850×560×2000 |
960×620×2100 |
|
Oil source cabinet dimension (mm) |
540×540×1300 |
|||
|
Main unit weight |
600 |
1200 |
1750 |
2200 |
|
Oil source cabinet weight |
210 |
|||
