Desktop Powder X-ray Diffractometer Xrd Machine Manufacturer

Name

Components

Unit

Qty

Remark

X-ray high-voltage generator

1) XRD40*600 X-ray generator

2) X27.06 high-voltage cable(75kVP)

3) 3311 pipe sleeve (including automatic optical shutter)

4) X25.02 stage(Metal shell)

5) DS2910/24 Metal ceramic insulation X-ray tube

set

1

high-frequency high-voltage

piece

1

Length:2.0 meter

set

1

set

1

Lead+ lead glass protection

piece

1

Cu target, 2.4kW

Angle measurement system

1) DG-3511 goniometer

2) Slit and powder sample holder

3) Through-hole sample plate

4) Blind-hole sample plate

5) Filter

6) Slit plate and lighting system adjustment accessories

set

1

θ-θ structure

set

1

One set for each

piece

5

Aluminium matrix

piece

10

Glass matrix

piece

1

Match with target material

set

1

Recording and controlling system

1) Closed proportional counter

2) Recording and controlling unit

3) Motor and communication cable

4) Power supply unit

set

1

Including 1 piece of connecting cable

set

1

piece

1

2 motor cables, 1 communication cable

set

1

PC system

1) Dell laptop; I3 processor; RAM:4G;  Hard drive: 500G;

2) A4 laser printer

set

1

DELL

set

1

System Control and Applicable Software

1) AL Series Diffractometer Control Program Software

2) Diffraction data processing software

3) Diffraction data card base

4) Crystal Structure Data Base

set

1

Windows OS

set

1

set

1

2009 version(59)

set

1

2010 version

Technical documents

1) AL series XRD user manual

2) Data Process and Applicable Software User Manual

copy

1

copy

1

Accessory

1) DCX-6 sample changer

set

1

2) Graphite monochromator

set

1

Reflectivity>28%

Spare parts

1) Fuses 1,1.5,2,2.5,3,3+(A)

2) Tools

3) Agate Mortar diameter100mm

Piece

10

10 pieces for each

set

1

set

1
