Home > Products > Solar cable > Single Core Pv1-f 1x2.5mm 1x4mm 1x6mm 1x25mm dc pv Solar Cable Wire Solar Cable for Solar Panel
Single Core Pv1-f 1x2.5mm 1x4mm 1x6mm 1x25mm dc pv Solar Cable Wire Solar Cable for Solar Panel
US$ 0.5 - 0.6
/ Meter
1000 Meters(Min. Order)
- SHEN ZHEN
- T/T Credit Card
You May Like
-
Ultraviolet Proof Pvc Insulation Tinned Copper PV1-F 4mm2 Solar Cable for Solar System PV Cable
-
High Quality 1.5mm2 1000V DC TUV Solar Cable 4mm2/12AWG PV Cable
-
1.5mm2 4mm2 6mm2 10mm2 16mm2 Wire Electrical dc Solar Cable for Solar Energy System
-
High Quality Multicore Battery 10 AWG 6mm2 Solar Cable Red or Black PV Cable Wire XLPE Jacket
-
Factory Price Tuv Approved Single Core Double Core PV1F Solar Cable 4mm2 6mm2 10mm2 Solar Cable for Solar Panel
-
High Quality Standard 1000V DC TUV Waterproof XLPE Double Insulation 4mm 12AWG Solar PV Cable
Product Details
| Brand Name | JZD | Place of Origin | Guangdong, China | |
| Model Number | solar cable | Type | Low Voltage | |
| Application | Power Station | Insulation Material | XLPE | |
| Jacket | PVC | Conductor Material | Copper |
Product Description
Product Description
Product features
Low smoke without halogen, good cold, ultraviolet, ozone - resistant and weather - resistant.
Flame retardant, cutting resistance and penetration resistance.
Cable protection level Ⅱ level.
With 150 ℃ photovoltaic cable radiation as insulation materials, halogen free flame retardant is halogen-free, non-toxic modified polyethylene thin hengjing resin as the main raw material, add halogen-free, non-toxic, flame retardant, heat stabilizer, eliminate smoke agent, preservative, such as fertilizer, does not contain halogen, heavy metals, phosphorus.
It conforms to ROHS, and the insulation resistance is small after immersion.
Electrical
1. The dc resistance: the finished cable at 20 ℃ conductive wire core dc resistance is not greater than 5.09 Ω/km
2. The insulation resistance: the finished insulation resistance of cable at 20 ℃ should not less than 1014 Ω. Cm, finished cable insulation resistance at 90 ℃ is not less than 1011 Ω. Cm
3. The sheath surface resistance: resistance of the finished cable sheath surface should be not less than 109 Ω.
Cable structure
Conductor: tinned copper wire 2.5, 4, 6, 10, 16 mm² 2 PV1 - F
18, 16 and 14, 12, 10, 8, 6, 4, 2 mm² PV wire
Insulation: > 0.5mm thick with low smoke and halogen material, and meet the specified limit of the customer.
Sheath: low smoke and halogen free material thickness > 0.5mm.
parameters
Ambient temperature: - 40 ℃ ~ + 90 ℃
The highest temperature of conductor: 120 ℃ (allow 5 s in short circuit temperature 200 ℃)
Limited voltage: AC0.6/1kv dc1.8kv.
