Driving Concrete Laser Screed RWJP14

Driving Concrete Laser Screed RWJP14 thumbnail-1
Driving Concrete Laser Screed RWJP14 thumbnail-2
Driving Concrete Laser Screed RWJP14 thumbnail-3
Driving Concrete Laser Screed RWJP14 thumbnail-4
Driving Concrete Laser Screed RWJP14 thumbnail-5
Driving Concrete Laser Screed RWJP14 photo-1
Driving Concrete Laser Screed RWJP14 photo-2
Driving Concrete Laser Screed RWJP14 photo-3
Driving Concrete Laser Screed RWJP14 photo-4
Driving Concrete Laser Screed RWJP14 photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
ROADWAY
Place of Origin:
China
Model Number:
RWJP14
Contact Supplier Request Quote Chat Now
Shandong Roadway Construction Machinery Manufacturing Co.,ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai/qingdao/tianjin
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name ROADWAY
Place of Origin China
Model Number RWJP14
After-sales Service Provided Engineers available to service machinery overseas
Weight 1200kg
Dimension(L*W*H) 2717 × 2760 × 2380mm
Voltage NO
Condition New
Power(W) 20HP / 3600rpm

VIDEO:/lnBjjKmloo-kqikKBljlmSRnikqrrnrlmppor-f258370889b94d4b8678e0d8e543a0b7

Technical Parameters

Engine

Screed system

Model

HONDA GX630 electric start

Screed head type

Swing type

Type

Gasoline engine,air-cooled, 4 stroke, OHV, double cylinder

Width

2500mm

Power

20HP / 3600rpm

Paving type

With auger

Fuel tank volume

40L

Auger force

hydraulic motor

Fuel consumption

313g / kWh

Exciting force

500N

Running system

Vibration frequency

50Hz

Drive

4 Hydraulic drive motor

Screed plate height

350mm

Running speed

0-35m / min

Operation mode

Laser control system

forward and reverse

Hand grip control, stepless speed walking

control method

Microcomputer laser scan

Steering

Hydraulic control

Control effect

Flat, slope or double slope (3D)

Cleaning system

Size and weight

Power

Hydraulic motor

Outline dimension

2717 × 2760 × 2380mm

Theoretical flow

20L / min

Weight

1200kg

Rated pressure

7MPa
Product Tags: Driving concrete laser leveler , Laser leveler , Concrete laser leveler , Six-wheel laser leveler
