AC DC current clamp meter
High Accuracy AC DC current clamp meter is specially designed for measurement of AC/DC current; by adopting up-to-date CT technology and digital integration technology. There is no exposed metal on clamp head, non-contact measurement, to ensure safe operation. It is a product with relatively small size, high accuracy and perfect function compared with similar leakers in the world. The leaker could be widely applied in those fields as electricity, communications, meteorology, railroad, oilfield, construction, measurement, scientific & research teaching institutes, industrial and mining establishments. it is an essential tool for electrician safety testing.
AC DC current clamp meter Parameter:
| Function | AC/DC leakage measurement, AC/DC current measurement, On-line AC/DC current measurement |
| Power Supply | 6F22,9V |
| Process Type | Clamp CT, noncontact mode. |
| Display Type | 4 Digits LCD |
| Clamp Size | 25mm×30mm |
| Meter Dimension | LWH: 175mm×70mm×38mm |
| LCD Dimension | 35mm×21.5mm; Display Dimension: 32mm×15mm |
| Sampling Rate | 2 Times/Second |
| Frequency | 50Hz, 60Hz Automatic identification |
| Shifting | Automatic Shift |
| Range | AC/DC:0.0A~1000A |
| Resolution | 0.1A |
| Accuracy | ±2%±3dgt (23℃±3℃, below 70%RH) |
| Line voltage | Below AC 600V |
| RS232 Interface | With RS232 interface, Data stored in the memory can be uploaded to the computer, with software monitoring |
| Data Memory | 99 sets, “FULL” Blinking when memory is full |
| Peak Maintaining | Peak value capture hold function, press HOLD without Release to display peak value |
| Reading Hold | Reading hold function: “DH” symbol display |
| Overflow display | Range overflow function: “OL” symbol display |
| Automatic Shutdown | 5 minutes after the boot |
| Battery Detection | When battery voltage is lower than 7.2V, low battery symbol will shown to remind battery replacement. |
| Meter Weight | 180g (With battery) |
| Rated Power | 10mW |
| Working Temperature and Humidity | 0℃~50℃; below 80%rh |
| Max error refer to environment | -10℃~0℃,40℃~50℃,Error will increase max to 1%rdg. |
| Storage Temperature and Humidity | -10℃~60℃; below 70%rh |
| Insulation Strength | AC2kV/rms (between core and box) |
| Safety Provisions | IEC1010-1, IEC1010-2-032, Pollution level 2, CAT Ⅲ(600V) |
| Accessories | Meter: 1 piece, RS232 Com-cable:1 piece; Software Disk: 1 piece; Battery (6F22 9V): 1 piece |
HuaZheng Electric Manufacturing (Baoding) Co.,Ltd (HuaZheng Electric for short), is a new enterprise engaged in development,produce & sale a serious of power system products. Our company rely on North China Electric power university and Hebei university and many other insititutions of higher leaning,combined product, learn and research together, mayor in electric power, electronic, microcomputer, automatic serious product, has developed a number of independent intellectual property rights, own advanced high-tech products inland,and successfully operate in electric,trrafic security and other field. ( AC DC current clamp meter )
AC DC current clamp meter
AC DC current clamp meter
