5 port 2 position internal pilot alloy material pneumatic electrical valve Model 4V310-10
1,5/2 way pneumatic control valve
2,Type: 200 series
3,Port size: 3/8"
Skype: CaoxL090
Model | 4V210-06 | 4V220-06 | 4V230C-06 | 4V230E-06 | 4V230P-06 | 4V210-08 | 4V220-08 | 4V230C-08 | 4V230E-08 | 4V230P-08 |
| 4A210-06 | 4A220-06 | 4A230C-06 | 4A230E-06 | 4A230P-06 | 4A210-08 | 4A220-08 | 4A230C-08 | 4A230E-08 | 4A230P-08 |
Valve type | 5/2 way | 5/3 way | 5/2 way | 5/3 way | ||||||
Effectiive area | 14 mm2(CV=0.78) | 12 mm2(CV=0.67) | 16 mm2(CV=0.89) | 12 mm2(CV=0.67) | ||||||
Model | 3V210-06 | 3V220-06 | 3A210-06 | 3A220-06 | 3V210-08 | 3V220-08 | 3A210-08 | 3A220-08 | ||
Valve type | 3/2 way | |||||||||
Effective area | 14 mm2(CV=0.78) | 16 mm2(CV=0.89) | ||||||||
Port size | Inlet , outlet,exhaust port=1/8" | Inlet, outlet=1/4", Exhaust port=1/8" | ||||||||
Working medium | 40 micron filtered air | |||||||||
Operation | Internal piloted pneumatic electrical valve | |||||||||
Working pressure | 0.15-0.8 Mpa | |||||||||
Max. pressure | 1.2 Mpa | |||||||||
Temperature | 5-50 degrees centigrade | |||||||||
Voltage tolerance | Plus or minus 10% | |||||||||
Power consumption | AC:5.5 VA, DC:4.8W | |||||||||
Connector protection | F Class, IP65 | |||||||||
Wiring/Connector | Cable/Lead wire or DIN connector | |||||||||
Frequency | 5 cycles/ sec | |||||||||
Response time | 0.05 sec | |||||||||
Skype: CaoxL090
Have stock for more than 100 sets of pneumatic electrical valve
