Common Rail Injection Pump Test Bench With Industrial PC Motherboard
- Qingdao or Shanghai
- T/T Credit Card
You May Like
-
Common Rail Diagnostic Calibrating Tools XBD-3000A Test Bench Specially Designed For Diesel Common Rail Injectors and Pumps
-
Trustworthy China Supplier Common Rail Diesel Injector Test Bench/fuel Injection Pressure Tester
-
CR708 CR3000A Common Rail Tester Common Rail Diesel Fuel Injector Pump Test Bench From Taian Manufacturer
-
XBD- CRSII Common Rail Injector Tester Multifunctional Diesel Fuel Injector Pump Tester
-
220V Pneumatic Common Rail Injector Tester
-
XBD-CRS815 Common Rail System Test Bench
Product Details
| Brand Name | XBD | Place of Origin | Shandong, China | |
| Model Number | XBD 3000A | Power | Electronic | |
| Usage | Auto Testing Machine |
Product Description
Common rail injection pump test bench with industrial PC motherboard
CR3000A uses test bench output power to drive common rail diesel pump, control fuel pressure with open or closed circle, and read the supplied and returned diesel amount from metering cylinder. The equipment can test and repair all models of Euro II in-line pump, and electronic high pressure common rail fuel injection pump, and nozzle tester with Euro III Emission Standard.
With easily operation and high efficiency, it can test high pressure common rail fuel injection system of many famous brands, like BOSCH, SIMENS, DELPHI, DENSO, etc., which has similar signal as ECU, driving one high pressure pump solenoid valve and six common rail diesel injector solenoid valve.
The common rail tester which based on standard diesel high pressure pump test bench, have good quality in high pressure common rail system repair testing, which includes fuel quantity of nozzle tester, uniformity, returned diesel amount of the nozzle, status of high pressure pump, rail pressure controlling, etc.. Our high pressure common rail diesel injection pump test bench has complete functions and reliable operation process. They are your best choice for repairing Euro III Emission Standard diesel system!
MAIN FEATURES:
1, Control output of multi-segment voltage automatically, and reach drive requirements of different common rail diesel fuel injection.
2, LCD color monitor displays frequency of high pressure common rail fuel injector and control drive pulse automatically.
3, Control the adjusting valve and flow of fuel pump injection automatically.
4, Realize constant voltage control of fuel pump and rail. Reach ±1MPa accuracy.
5, Choose open or closed circle control manually.
Data of common rail test bench
Main motor speed | 0-4000 r/min, can be adjustable |
Motor power | 5.5kw |
Fuel Injector open voltage | Control range: 12v, 80v, 150v Control accuracy: phase adjustment |
Injector opening frequency control | 0-1000HZ Control accuracy: 1HZ
|
Fuel injector hold time | Control range: 0-65535us |
Delivery oil count | Control times: 0-1000times Control accuracy: 1 time |
Fuel pressure control | 0-2000 bar Control accuracy: 1bar |
Electronic power | 3 phase 380V / 3 phase 220V optional |
Workshop

Other products
We have more model products for testing traditional mechanical pump.
Such as XBD-CR100 common rail system test bench by
https://www.china.cn/product-detail/High-Quality-Diesel-Powered-Common-Rail_1476062888.html?spm=a2747.manage.list.520.7ecb3004Spx6k8
You can also check more information by
https://xinbaodi.en.china.cn/productgrouplist-209578007/Diesel_Fuel_Injection_Pump_Test_Bench_Series.html?spm=nav.5.5b9555bfH8uwzt
Certificate


Contact
TAIAN XINBAODI EXPERIMENTAL EQUIPMENT CO., LTD
Add : NO. 1#-2-402,WEST OF DONGYUE STREET, TAIAN CITY, SHANDONG, CHINA
Mob:0086-13562896072
WeChat: 0086-13562896072
WhatsApp: 0086-13562896072
Skype: testbench201010
E-mail: testbenchina*
Website: https://xinbaodi.en.china.cn
FAQ
Q: How many days to produce this test bench?
A: It need 5-20 days to produce the test bench.
Q:How can I pay for it?
A:We support TT payment, West Union, and L/C etc.
Q:How to sign an order?
A:We can sign an order offline or online on Ali.
Q:How long of warranty?
A:12 months
Q:Do you have some repairing tools?
A:Yes, we have many kinds of repairing tools for common rail injector and pump.
