SIEMENS 1TL0001 1.1kw 2p Low Voltage Three-phase Asynchronous AC Motor
US$ 80 - 80
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
SIEMENS BEIDE
Place of Origin:
Jiangsu, China
Model Number:
1TL0001
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SIEMENS 1TL0001 1.5kw 2.2kw 2p Low Voltage Three-phase Asynchronous AC MotorUS$ 94 - 100MOQ: 1 Piece -
ABB M2BAX Low Voltage 3kW Three Phase Squirrel Cage ac Induction MotorUS$ 240 - 240MOQ: 1 Set
-
SIEMENS 1TL0001 11kw 15kw 2p Low Voltage Three-phase Asynchronous AC MotorUS$ 400 - 445MOQ: 1 Piece
-
SIEMENS 1TL0001 45kw 2p Low Voltage Three-phase Asynchronous AC MotorUS$ 1,204 - 1,204MOQ: 1 Piece
-
SIEMENS 1TL0001 55kw 2p Low Voltage Three-phase Asynchronous AC MotorUS$ 1,516 - 1,516MOQ: 1 Piece
Brand Name
SIEMENS BEIDE
Place of Origin
Jiangsu, China
Model Number
1TL0001
Company Profile
Siemens Standard Motors Ltd. (SSML)
Siemens Standard Motors Ltd. (SSML) is a Siemens-owned company in China. SSML is located in Yizheng City, Jiangsu Province. The company focuses on developing and producing small and medium low-voltage motors. Currently, SSML mainly produce Siemens brand low voltage AC motors according to IEC standards, and Beide brand low voltage motors designed according to China local standards.
As one of Siemens main low-voltage motor production facilities worldwide, SSML uses the knowledge and experience of more than 100 years in motor design and manufacturing, owns the advanced manufacture equipment and process, adopts the SIEMENS modern management model , and implements comprehensive quality control according to ISO9001 2008. SSML will continuously serve customers with high quality products and good service.
Product Description
Siemens 1TL0 SERIES
1TL0 series of motors is the newly designed high effificiency low voltage three phase asynchronous motor, the housing material is cast iron, is designed for continuous duty operation(S1). 1TL0 series of motors owns the features of high efficiency, novel structure, beautiful appearance, low
noise, small vibration, high degree of insulation, etc, also can be used in the fifields of fans, pump, compressors and textile machine.
By adopting the 1TL0 series of motors, customer can save energy up to 10%, which contributes to upgrading the status of the industry and enhancing the competitive power of the products.
Product Show
Product Specificate
Frame Size |
Order No. |
Rated Output |
Rated Speed |
80M |
1TL0001-0DA32-1AA5 |
1.1kw |
2835 |
80M |
1TL0001-0DA32-1FA5 |
1.1kw |
2835 |
Rated Output
1TL0 motors rated output powers means that the motor runs under continuous duty S1 (IEC 60034 -1) operation when operated at ambient temperature from -15 ºC to 40 ºC and at altitudes of up to 1000 m over sea.
Voltage and Frequency
IEC 60034-1 differentiates between Category A (combination of voltage deviation ±5 % and frequency deviation ±2 %) and Category B (combination of voltage deviation ±10 % and frequency deviation +3 % / -5 %) for voltage and frequency flfluctuations. The motors can supply their rated torque in both Category A and B. In Category A, the temperature rise is approximately 10 K higher than during normal operation.
Standard 60034-1 |
Category A |
Category B |
||
Voltage deviation |
±5% |
±10% |
||
Frequency deviation |
±2% |
+3% / -5%% |
||
According to the standard, longer operation is not recommended for Category B. |
||||
Ordering Information
Packing & Delivery
Packaging |
||
Size |
335 (L) * 270 (W) * 270 (D)mm |
|
Weight |
17.5kg |
|
Packaging Details |
The normal package is carton box(Size: 350*300*300). If export to european countries,the wooden box will be fumigated.If container is too tigher, we will use pe film for packing or pack it according to customers special request. |
|
Detailed Images
Machine Parts
Name: SIEMENS MOTOR
Brand: SIEMENS
Original: CHINA
World famous brand motor, efficient, economic, environmental protection, improve the company's production efficiency.
Main Features
Name: ABB MOTOR
Brand: ABB
Original: CHINA
World famous brand motor, efficient, economic, environmental protection, improve the company's production efficiency.
Machine Parts
Name: TECO MOTOR
Brand: TECO
Original: CHINA
World famous brand motor, efficient, economic, environmental protection, improve the company's production efficiency.
