Product Details
| Brand Name | Original | Place of Origin | China | |
| Model Number | BDH10-RK1-U | Type | Switch Box | |
| Protection Level | Other |
Product Description
BDH10-RK1-U 24KV 630A 50/60Hz Medium Voltage Switchgear
Product Type & Parameters
| Type | Rated Voltage (KV) | Rated Current (A) | Rated frequency (Hz) |
| BDH10-RK | 24KV | 630A | 50/60Hz |
| BDH10-RK1 | 24KV | 630A | 50/60Hz |
| BDH10-RK1V | 24KV | 630A | 50/60Hz |
| BDH10-RK1-U | 24KV | 630A | 50/60Hz |
| BDH10-RK1V-U | 24KV | 630A | 50/60Hz |
| BDH10-K | 24KV | 630A | 50/60Hz |
| BDH10-K-U | 24KV | 630A | 50/60Hz |
| BDH10-TR1 | 24KV | 630A | 50/60Hz |
| BDH10-TR1-V | 24KV | 630A | 50/60Hz |
| BDH10-TR-V | 24KV | 630A | 50/60Hz |
| BDH10-TR1-U | 24KV | 630A | 50/60Hz |
| BDH10-R-B2 | 24KV | 630A | 50/60Hz |
| BDH10-R-B3 | 24KV | 630A | 50/60Hz |
| BDH10-T-B2 | 24KV | 630A | 50/60Hz |
| BDH10-T-B3 | 24KV | 630A | 50/60Hz |
| BDH10-RT-B2 | 24KV | 630A | 50/60Hz |
| BDH10-2RT-B3 | 24KV | 630A | 50/60Hz |
| BDH10-3RT-B4 | 24KV | 630A | 50/60Hz |
| BDH10-KT-B2 | 24KV | 630A | 50/60Hz |
| BDH10-LS1 | 24KV | 630A | 50/60Hz |
| BDH10-LS1-U | 24KV | 630A | 50/60Hz |
| BDH10-LS1V/LS2 | 24KV | 630A | 50/60Hz |
| BDH10-LS2 | 24KV | 630A | 50/60Hz |
| BDH10-LS1V-U/LS2-U | 24KV | 630A | 50/60Hz |
| BDH10-LK/LT1 | 24KV | 630A | 50/60Hz |
| BDH10-LKV/LT1-V | 24KV | 630A | 50/60Hz |
| BDH10-LT2 | 24KV | 630A | 50/60Hz |
| BDH10-SE | 24KV | 630A | 50/60Hz |
| BDH10-SE1V/SE2 | 24KV | 630A | 50/60Hz |
| BDH10-MS1V/ME3 | 24KV | 630A | 50/60Hz |
| BDH10-ME1 | 24KV | 630A | 50/60Hz |
| BDH10-ME1-K | 24KV | 630A | 50/60Hz |
| BDH10-ME1-S | 24KV | 630A | 50/60Hz |
| BDH10-ME1-KS | 24KV | 630A | 50/60Hz |
| BDH10-ME1-KK | 24KV | 630A | 50/60Hz |
| BDH10-ME2 | 24KV | 630A | 50/60Hz |
Technical Characteristic
1. Maintenance-free
2. Climate-independent
3. Partition class: Class PM
(metallic partition)
4. Three-pole primary enclosure,
metal-enclosed
5. Insulating gas SF6
6.Welded switchgear vessel without seals, made of stainless steel, with welded-in bushings for electrical connections and mechanical
components
7.Three-position switch-disconnector with load-break and make-proof earthing function
8 Cable connection for bushings with outside cone
9. Connection with cable plugs
– In ring-main feeders and circuit-breaker feeders with bolted contact (M16)
– In transformer feeders with plug-in contact
10. Option: Connection with conventional cable sealing ends
– For thermoplastic-insulated cables via elbow adapter AKE 20 / 630 (make Siemens)
– For paper-insulated massimpregnated cables via commercially available adapter systems
11. Easy installation
12. Option: Pressure absorber system
– Maintenance-free
– For rated short-time withstand current Ik 20 kA
– For single andmulti-panel combinations of 700 mmto 2000 mmwidth (for panel type ME1 withmax. 1 adjacent panel)
– With 300 mmhigh pressure absorber duct below the switchgear and
– With 115mmdeep pressure absorber duct for pressure relief upwards
–With screwed-on cable compartment cover
– Possible for switchgear with standard cable compartment cover
Option: Deeper cable compartment cover: 105 or 300 mm
– For overall height of switchgear, see page 6
– Option: Free-standing arrangement, for overall height of switchgear 2300 mmand with rear cover
Application
Customer transfer substation in an accessible switchgear building(transformers, medium-voltage and low-voltage in a factory-assembled building).
Power supply of high-rise buildings
