Price for Swing Arm Mini Crawler Excavator NM-E09 With KP192 Engine
US$ 4,200 - 4,400
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
nuoman
Place of Origin:
Shandong, China
Certification:
CE ISO
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Price for Mini Digger Excavator 1.0 Ton Use in GardenUS$ 4,180 - 4,280MOQ: 1 Set -
Price of Super 1.3 Ton Mini Crawler Excavator for Dugging DitchesUS$ 6,000 - 8,000MOQ: 1 Set
-
NM-E11 Mini Crawler Excavator With Hydraulic Oil Radiator for Sale by ManufacturerUS$ 4,800 - 5,100MOQ: 1 Set
-
Price for 1.5 Ton Mini Hydraulic Crawler Excavator With 3T NV70 EngineUS$ 5,904 - 9,672MOQ: 1 Set
-
Price for 1.6 Ton Mini Crawler Hydraulic Excavator With CE CertificateUS$ 11,300 - 11,324MOQ: 1 Set
Brand Name
nuoman
Place of Origin
Shandong, China
Certification
CE ISO
Condition
New
Moving Type
Crawler Excavator
Rated Speed
1.5km/h
Max Digging Radius
2450mm
Maximum Digging Depth
1220mm
Maximum Digging Height
2400mm
Bucket capacity
0.02m3
Operating Weight
800kg
Product Description
As an experienced manufacturing company with a group of professional and responsible employees,all our product descriptions on all our details pages are guaranteed to be accurate!!!
Low fuel consumption, wide scope of operation, suitable for loose land in vegetable shed, landscaping in municipal departments, planting of trees and pits in orchard nurseries, broken concrete pavement, agitation of sand and stone, construction of narrow space, etc., Can equipped with rotary drilling, broken hammer, loading bucket, grab, etc., reduce maintenance and operation costs, liberate labor force, improve mechanization, low investment, high return.
Technology parameter
| Model | NM-E08 | |||
| Type of tracks | Rubber | |||
| Engine | Model | KP-192F | ||
| Output | HP (kW)/rpm | 11.5 (8.6) / 2200 | ||
| Displacement | cu.in. (cc) | 20 (569) | ||
| Dimensions | Overall length | ft.in. (mm) | 8'2" (2480) | |
| Overall height | ft.in. (mm) | 3'9" (1150) | ||
| Overall width | ft.in. (mm) | 2'6" (722) | ||
| Platform clearance | in. (mm) | 15" (380) | ||
| Hydraulic system | Pump capacity | gpm. (l/min) | 5.55 (21.0) | |
| Auxiliary hydraulic flow | gpm. (l/min) | 5.55 (21.0) | ||
| Max. breakout force | Bucket | kn. (kgf) | 7.5 (760) | |
| Arm | lbs. (kgf) | 1010 (460) | ||
| Drive system | Travel speed | mph (km/h) | 1.2 (2.0 ) | |
| Max. traction force | kn. (kgf) | 6.5 (660) | ||
| Tumbler distance | ft.in. (mm) | 2'72" (800) | ||
| Crawler length | ft.in. (mm) | 3'8" (1140) | ||
| Shoe width | in. (mm) | 7.1" (180) | ||
| Ground contact pressure | Kpa(kgf/cm2) | 20 (0.20) | ||
| Swing system | Unit swing speed | rpm | 8.3 | |
| Boom swing angle | Left | degree | 55 | |
| Right | degree | 60 | ||
| Blade | Dimensions | Width | in. (mm) | 2'4" / (700 ) |
| Height | in. (mm) | 7.9" (200) | ||
| Max. lift above ground | in. (mm) | 8.0" (210) | ||
| Max. drop below ground | in. (mm) | 4.9" (125) | ||
| Hydraulic oil (reservoir/system) | gpm. (l/min) | 3.30 / (12.5) | ||
| Fuel reservoir | gpm. (l/min) | 3.17 (12.0 ) | ||
| Operating weight | lbs.(kg) | 1804 (820 ) | ||
| Including operator’s weight 175 lbs. | ||||
