3000kN Cement Concrete Compression Test Device
Functions and applications:
1) Adopting manual control, hydraulic loading, electronic measurement, computer display and data auto processing, it can perform compression test for metallic and nonmetallic materials;
2) Controlled by oil inlet and oil outlet valves, easy operation, with attractive appearance;
3) Four columns, underneath type oil cylinder, easy for installation, with good stability;
4) With reserved interface for connection with internet or computer, used for upgrading;
5) Equipped with accessories, it can perform compression tests for other materials.
Technical parameter:
No. |
Items |
Technical parameters |
1 |
Max. test force (KN) |
3000 |
2 |
Measuring range of test force (KN) |
2%-100%FS |
3 |
Accuracy of indicating value |
≤±1% |
4 |
Max. compression space (mm) |
0-350 |
5 |
Distance between two columns (L*W) mm |
500*400 |
6 |
Size of spherical upper platen (mm) |
diam.300 |
7 |
Size of square lower platen (mm) |
400*400 |
8 |
Max. stroke of pistion (mm) |
150 |
9 |
Loading rate |
0-40KN/s, adjustable |
10 |
Dimension of main machine (L*W*H) mm |
700*600*1800 |
11 |
Dimension of control cabinet (mm) |
570*480*1230 |
12 |
Weight (kg) |
About 1200 |
3000kN Cement Concrete Compression Test Device
