10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine

10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine thumbnail-1
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine thumbnail-2
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine thumbnail-3
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine thumbnail-4
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine thumbnail-5
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine thumbnail-6
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine thumbnail-7
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine photo-1
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine photo-2
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine photo-3
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine photo-4
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine photo-5
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine photo-6
10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile Strength Testing Machine photo-7
US$ 6,000 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HST
Place of Origin:
Shandong, China
Model Number:
WDW-100
Contact Supplier Request Quote Chat Now
Jinan Hensgrand Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HST
Place of Origin Shandong, China
Model Number WDW-100
Power Electronic

WDW-30 kn  Universal Computer Tensile Strength  Waterproof Tester

 10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine

1. Application:

This series mainly used for tensile, compression, peal, shear, tear, and bending mechanical property test for metal, non metal material. Widely used in aerospace, petrochemical industry, machinery manufacturing, plastic, rubber, ceramic building materials, metal materials, construction and other industries, and institutions of higher learning, scientific research institutions, technical supervision, Quality Inspection Station and so on.



2.Technical parameters: skype:hssdtest wechat/whatspp:8615098778967

Model

WDW-10/20//30

WDW-50

WDW-100

  WDW-200/ 300

WDW-500/ 600

Max. Load

10kN

20kN

30kN

50kN

100kN

   200kN

300kN

500kN

600kN

Structure

Four-column Floor Type (upper is compression and lower is tensile)

Control model

Computer control

Constant stress, constant strain,constant

displacement closedloop control System

Load accuracy

1 class/ 0.5 class optional

Load range

2%-100% of full scale /0.4%-100% optional

Load resolution

1/300000

Deformation test range

 2%~100%

Deformation accuracy

≤±1%

Displacement accuracy

≤±1%

Disp. resolution

0.04um

Displacement speed

0.05-500mm/min

0.05-200mm/min

Tensile space

800mm

700mm

700mm

550mm

700mm

Compression space

800mm

700mm

700mm

550mm

700mm

Test width

400mm

400mm

450mm

600mm

500mm

Clamp way

Manual clamp / Hydraulic clamp (optional)

Hydraulic

clamp

Load Cell Configuration

One(max load), more load cells can be added according to

 customer requirement

Extend configuration

Large deformation extensometer, high or low

temperature teste chamber, high temperature oven

Power supply

AC220/380V±10%,50Hz (can be customized)





More Information

10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine

10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine

10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine10kN-100kN 10Ton Computer Controlled Electronic Universal Tensile strength Testing Machine Skype: hssdtest wechat/whatapp/tel: 8615098778967
