100-240V DELTA ES2 Series DVP-32ES200RC Standard PLC With Built-in CANopen Interface

DELTA DVP-ES2 Series PLC DVP-32ES200RC/TC

Program capacity: 16k steps
Built-in with 3 COM ports: 1 RS-232 port and 2 RS-485 ports, all are able to operate independently (Master/Slave)
Max. I/O points: 256 input points + 16 output points, or 256 output points + 16 input points
DVP-EX2 MPU is built in with 12-bit 4AD/2DA and offers analog/temperature modules of 14-bit resolution.
Built-in with 8 high-speed input points (2 points for 100kHz, 6 points for 10kHz) and supports U/D, U/D Dir, A/B counting modes
New motion control instructions: Close loop control, alignment mark, shield, immediate variable speed, S-Curve acceleration/deceleration
Application in emerging industry: Exclusive instructions and function blocks designed for PV solar tracker
Handy instructions for frequency inverter: For controlling the forward running, reverse running, RUN and STOP of Delta@@s AC motor drives
Password protection: Password for subroutine, user ID, restriction on trial times
Highly efficient instruction efficient instruction execution

Boosts productivity with high execution speed and built-in CANopen interface, and specializes in noise-immunity and easy wiring

Built-in 1Mbps CANopen interface; COM3 supports standard CANopen DS301 protocol
Versatile communication types: PDO, SDO, synchronous (SYNC), Emergency, NMT and many more
1Mbps high-speed transmission for large data:- Max. PDO transmission: up to 390 bytes- Max. PDO receiving: up to 390 bytes
Ability to connect with 16 slaves via CANopenBuilt-in 1 RS-232 and 1 RS-485 ports
