Product Details
| Brand Name | Huadong control cable. | Place of Origin | Henan, China | |
| Model Number | YSLYCY-JB cable | Application | Instrumentation | |
| Insulation Material | PVC | Jacket | PVC | |
| Conductor Material | Copper |
Product Description
Conductor material: Bare copper
Conductor construction: Fine stranded, class 5
Insulation: PVC YI2
Inner sheath: PVC
Screen: Cu-braiding
Screen coverage: 70 %
Sheathing material: PVC TM2
Colour of outer sheath: Gray RAL 7001
Flame retardant: VDE 0482-332-1-2/IEC 60332-1
Maximum temperature at conductor: 70 ° C
Max. Operating temperature, fixed: -40 - +70 ° C
Temperature, moved/during installation: -5 - +70 ° C
Bending radius, fixed installation: 6 x DA
Bending radius, moved application: 20 x DA
Nominal voltage Uo: 300 V
Nominal voltage U: 500 V
Test voltage: 2 kV
Core identification: Gn-ye + numbers
Application: Flexible power, process control and instrumentation cable for industry and machinery environment withIncreased requirements to electromagnetic compatibility. The cable is resistant against most usual chemicals, oil andGrease.
| Type | Specification | Rl. | DA. | Cu. | G. |
| No. x mm2 | [Ω/km] | [mm] | [kg/km] | [kg] | |
| YSLYCY-JB | 04X4 GR | 4,95 | 12,7 | 290 | 320 |
| YSLYCY-JB | 04X6 GR | 3,3 | 15,7 | 360 | 470 |
| YSLYCY-JB | 04X10 GR | 1,91 | 19,2 | 535 | 740 |
| YSLYCY-JB | 04X16 GR | 1,21 | 22,9 | 910 | 1450 |
| YSLYCY-JB | 04X25 GR | 0,78 | 28,4 | 1310 | 1520 |
| YSLYCY-JB | 04X35 GR | 0,554 | 33,5 | 1693 | 2010 |
| YSLYCY-JB | 04X50 GR | 0,386 | 40,5 | 2342 | 2840 |
| YSLYCY-JB | 04X70 GR | 0,272 | 47,5 | 3090 | 3880 |
| YSLYCY-JB | 04X95 GR | 0,206 | 53,2 | 4060 | 5070 |
| YSLYCY-JB | 04X120 GR | 0,161 | 55,2 | 5299 | 6430 |
| YSLYCY-JB | 04X150 GR | 0,129 | 70,1 | 7033 | 7650 |
| YSLYCY-JB | 04X185 GR | 0,106 | 62,1 | 9023 | 9300 |
cable HFX-U-FR 19x1.5 mm 150m 7x2x0.75 250m XLPE insulation cable HF-TXCS 4x2x0.75 mm .
1,100 to 1,000m reeled in carton drum or according to customers' requirement.
2) Outer packing: wooden case, carton box.
3) Other packing requirement according to client's request.
cable HFX-U-FR 19x1.5 mm 150m 7x2x0.75 250m XLPE insulation cable HF-TXCS 4x2x0.75 mm .
1. We guarantee to offer new advanced goods.
2. We'd like to send skilled personnel to the installing place to help offer technical consultant, quantity estimation and instruction,installing, preliminary testing,and help start up running; and to answer for any defect of the product found in installing and run testing, If there's something wrong with the product, we'll give our answer within 12 hours and get to the spot within 36 hours.
3.After installaton, We'll send skilled personnel to have the preliminary test and answer for any problems emerged. We take the whole charge of the fee needed in repairing,testing or retesting within the scope of our duty required in contract.
4.During the contract's period of validity,of the project must be started all over again or the goods can not be used at all which is resulted from our faulty goods and improper files or mistakes made by our instructors, we'll change the goods at once without compensation and take charge in all expenses of reinstallation.
Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated incable production, research & development,and domestic& international trade.
Established year: 2005
Total asset: USD 32 million
Plant area: 30000 m2
Number of staff: 380
Engineer:20
Laboratory Inspector: 18
Production line: 18
Testing machine:25
Producing capacity each year: 320000 km.
control cable Standard:
Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA and so on.
Meanwhile we can produce based on customers' requirements and specifications.
control cable Certificate:
The company has passed ISO90012008 quality certification, CCC China Compulsory Certification, National Electrical
Product Safety Certification, State Construction and ProjectCommitee Recommended Manufacturer of the Transformation
of Urban and Rural Power Grid Construction.
1.what is our payment term ?
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.
2.what is the lead time ?
The lead time usually is 10 - 30 working days.
3.what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.
4.Could we provide the free sample for customer ?
Sure, we provide the free sample for customer to checking.
