Home > Products > Marine Piping & Valve System > Carbon Steel Resistance Pipe Explosion-proof Flame Arrestor
Carbon Steel Resistance Pipe Explosion-proof Flame Arrestor
- 5000 Set / Sets per Month
- Chongqing Shanghai Shenzhen Qingdao
- T/T Credit Card
You May Like
-
ANSI Stainless Steel Fire and Explosion Protection Breath Valve
-
Stainless Steel Explosion-proof Vacuum Breathing Valve
-
Stainless Steel Natural Gas Explosion Proof Flame Arrestor
-
Stainless Steel Natural Gas Pipeline Explosion-proof Flame Arrester
-
WCB Natural Gas Explosion-proof Flame Arrester
-
Normal Open Threaded Gas Pipeline Emergency Disconnection Solenoid Valve
Product Details
| Brand Name | BOCHI | Place of Origin | Chongqing, China | |
| Model Number | BMMVPPSFA | |||
| Standard or Nonstandard | Standard | |||
| Power | Hydraulic | Port Size | 20~200 | |
| Media | Oil | Temperature of Media | Low Temperature |
As customer required.">Flame Arrester:Packed in carton,
As customer required.
Product Description
Carbon Steel Resistance Pipe Explosion-proof Flame Arrestor
Flame arrester is suitable for the pipeline,a class of flash point less than 28 ℃,oil,hydrogen and oxygen liquefaction class.
product picture
product drawing
product parameter
Model | DN | Dimension(mm) | ||||
D | K | DL | L | n-*d | ||
BMMVPPSFA001 | 20 | 105 | 75 | 195 | 200 | 4×14 |
BMMVPPSFA002 | 25 | 115 | 85 | 195 | 200 | 4×14 |
BMMVPPSFA003 | 32 | 135 | 100 | 245 | 220 | 4×18 |
BMMVPPSFA004 | 40 | 145 | 110 | 245 | 240 | 4×18 |
BMMVPPSFA005 | 50 | 160 | 125 | 245 | 240 | 4×18 |
BMMVPPSFA006 | 65 | 180 | 145 | 245 | 240 | 4×18 |
BMMVPPSFA007 | 80 | 195 | 160 | 280 | 270 | 8×18 |
BMMVPPSFA008 | 100 | 215 | 180 | 335 | 280 | 8×18 |
BMMVPPSFA009 | 125 | 245 | 210 | 380 | 300 | 8×18 |
BMMVPPSFA010 | 150 | 280 | 240 | 460 | 360 | 8×22 |
BMMVPPSFA011 | 200 | 335 | 295 | 520 | 420 | 12×22 |
Valve equipment is important equipment for marine, Bochi Marine Group could disign and offer you best products with good servces: we take care of ur order!
We are one of the manufacturers of marine equipments in China. Located in Chongqing, which is among the largest industrial and commerical cities in China.
We are Alibaba Excellent Supplier & Alibaba Recommended Supplier!
With the aim of "to establish a close strategic partnership and develop together with customers", we will work whole-heartedly to improve our products and service .
Q:What can you offer classification society certificate?
A: BOCHI can supply CCS, ABS, DNV, GL, LR, RINA, BV, NK, KR, RS...etc.
We can satisfy all the customers requirments.
Q: How long is your delivery time?
A: BOCHI delivery time usually is 15-20 days.
According to customer's order quantity.
Q: How about your products quality?
A: All products flow are our manufacture bases,so so we can guarantee the quality of our products.
We have a professional after-sales service.
Any questions or unclear about the product,contact me please!
I must give your my sincerely answer in 24 hours!
