Marine Hydraulic/Electric Tug Boat Crane
- Shanghai Port
- T/T Credit Card
You May Like
Product Details
| Brand Name | BOCHI, BOCHI | Place of Origin | Chongqing, China | |
| Model Number | BMMDMMC-001 | Certification | ISO, GB, CCS,ABS,BV,RS,GL | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | 1 Year | |
| Application | All ships and vessels, Marine Deck | |||
| Max. Lifting Load | 10T | Span | 10m | |
| Rated Lifting Moment | Standard | Rated Loading Capacity | 10T | |
| Max. Lifting Height | 12m |
Standar Exported Package
Product Description
Marine Hydraulic/Electric Tug Boat Crane :
Main Technical Specification | ||||||||
Product No. | Safety Load | Working range | Lifting speed | Amplitude time | Folding arm time | Rotation speed | Rotation angle | Motor Power |
BMMDMHKBC-001 | 0.5 | 2.5~8 | 0~20 | ≤50 | ≤50 | 0.8 | 360 | 7.5 |
BMMDMHKBC-002 | 1 | 2.5~8 | 0~20 | ≤50 | ≤50 | 0.8 | 360 | 11 |
BMMDMHKBC-003 | 2 | 3~10 | 0~20 | ≤60 | ≤60 | 0.8 | 360 | 15 |
BMMDMHKBC-004 | 3 | 3~12 | 0~20 | ≤65 | ≤65 | 0.8 | 360 | 18.5 |
BMMDMHKBC-005 | 5 | 3.5~15 | 0~20 | ≤70 | ≤70 | 0.8 | 360 | 30 |
BMMDMHKBC-006 | 10 | 3.5~18 | 0~20 | ≤70 | ≤70 | 0.8 | 360 | 45 |
Main Dimensions | ||||||||
Product No. | L | D1 | D2 | D3 | n | L1 | L2 | |
BMMDMHKBC-001 | 2500 | 620 | 685 | 725 | 18-18 | 600 | 1000 | |
BMMDMHKBC-002 | 3200 | 740 | 800 | 880 | 24-20 | 800 | 1000 | |
BMMDMHKBC-003 | 3200 | 740 | 800 | 880 | 24-20 | 800 | 1200 | |
BMMDMHKBC-004 | 4500 | 1000 | 1150 | 1250 | 36-26 | 1000 | 1200 | |
BMMDMHKBC-005 | 5500 | 1600 | 1720 | 1830 | 54-30 | 1200 | 1500 | |
BMMDMHKBC-006 | 6000 | 1800 | 1950 | 2080 | 54-33 | 1500 | 1500 | |
All the details including Drawing and Data are changeable according to customer's requirements. | ||||||||
Application:
Open sea
Ship to ship
Continious operation
Basic features:
Self contained unit with integrated power pack
Simple mounting by welding of the pedestal to deck and connecting the power cable
No electric slipring
Fail-safe brakes on all movements
Welded box boom (jib) for low maintenance
Maintenance-free jib- and cylinder bearings.
Standard equipment:
Class certificate on the pedestal
Control platform on the crane (left or right-hand side)
Full documentation/Owner's manual
Working radius and lifting capacity (SWL) according to customer’s request

1. Punctual delivery time:
- We put your order into our tight production schedule, keep our client informed about production process, ensure your punctual delivery time.
- Shipping notice/ insurance to you as soon as your order is shipped.
2. After sales service:
- After receive the goods, We accept ur feedback at first time.
- We could provide installation guide, if you have need, we could give you global service.
- Our Sales are 24-hours online for ur request
3. Professional sales:
- We value every inquiry sent to us, ensure quick competitive offer.
- We cooperate with customer to bid tenders. Provide all necessory docuement.
- We are a sales team, with all techinical support from engineer team.
Bochi Have many global clients, we offer professional service to them. With the aim of "to establish a close strategic partnership and develop together with customers", we will work whole-heartedly to improve our products and service. We will also pledge to work jointly with business partners to elevate our cooperation to a higher level and share success together with our customers. We are looking forward to establishing relationships with you in the near future.

BOCHI Marine/Ship Equipment Department is a total solution provider with his head office in Bochi Corporation (Chongqing).we are able to provide value added services and qualified marine equipments.
Deck equipments is one of our main products.including mooring winch, windlass, capastan, steering gear, marine crane, deck fiitings, shark jaw and towing pin, stern roller, hydraulic pump station, davit, etc.
Certificate
For Marine Equipments, we could offer good quality with class certificate, including ABS, BV, CCS, DNV,GL, LR, KR,NK,RINA,RMRS ,etc.
