32kw ~ 55kw 4 Cylinder 4D Series Boat Diesel Engine
- Any port in China
- T/T Credit Card
You May Like
Standard export wooden box or as your requests.....
Product Description
1.This series of diesel engine are developed with German FEV
2.Cylinder head and boby are using alloy cast iron,high enhance degree,using integral shaft ,sliding bearing,small and light,high reliability
3.high-performance combustion chamber and Intake Swirl,fuel consumption indicator is far superior to the other same power products
4.using proprietary piston ring sealing technique,the consumption of lubricate is much lower
5.Suitable for small boat , fishing boat main engine and 20~40kw auxiliary engine
4D Series | ||||||||||
Model | Power/Speed | Intake way | Displacement | Net weight | Length*Width*Height | Flywheel | Encloser | Function | ||
Continuous | One-hour | (L) | (Kkg) | (mm) | ||||||
BMMPPDEY4108CA | 32/1500 | 35.2/1548 | Normally Aspirated | 4.214 | 370 | 986*730*948 | SAE 11.5 | SAE 3 | main engine/ auxiliary engine | |
BMMPPDEY4108C | 40/1500 | 44/1548 | Normally Aspirated | 4.214 | 370 | 986*730*948 | main engine/ auxiliary engine | |||
BMMPPDEY4108ZC | 50/1500 | 55/1500 | turbocharge | 4.214 | 390 | 986*730*1254 | main engine/ auxiliary engine | |||
BMMPPDEY4D75C | 55/1800 | 55/1858 | turbocharge | 4.214 | 390 | 986*730*1254 | main engine/ auxiliary engine | |||
Model | BMMPPDEY4108C | BMMPPDEY4108CA | BMMPPDEY4108ZC | BMMPPDEY4D75C |
| Type | Vertical,in-line,water-cooled,4 stroke | |||
| Intake way | Normally Aspirated | exhaust gas turbocharge | ||
No. of Cylinder - bore*stroke | 4-108*115 | |||
| Dispalcement (L) | 4.214 | |||
| Compression ratio | 17:1 | |||
| Continuous power/speed (kW/r/min) | 40(54)/1500 | 32(43.5)/1500 | 50(68)/1500 | 55(75)/1800 |
| One-hour power/speed (kW/r/min) | 44(60)1548 | 35.2(48)/1548 | 55(75)/1548 | 60.5(82)/1858 |
| Min.specific fuel consumption (g/kW·h) | ≤200 | ≤198 | ||
| Specific Oil Consumption (g/kW·h) | ≤0.8 | |||
| Crank shaft rotation direction | counter-clockwise(seen from the power output end) | |||
| Net mass (kg) | 370 | 390 | ||
| Overall demension(L*W*H) (mm) | 986*730*948 | 986*730*1254 | ||
| Ruduction gearbox to be matched | MB142,40A,MB170,MBS170… | |||
We can supply all scopes of marine engine,from 10kw-3000kw.If you need engines,don't miss us.Please feel free to contact us.We can provide you best service and prices!
wooden cases or as your request.
1. We are one of the suppliers of marine equipments in China. Located in Chongqing, which is among the largest industrial and commerical cities in China.
2. We operate as the import and export branch of Chongqing BOCHI Machinery Group.
3. We are Alibaba Excellent Supplier & Alibaba Recommended Supplier!
4. With the aim of "to establish a close strategic partnership and develop together with customers", we will work whole-heartedly to improve our products and service .
5. We can supply all kinds of marine diesel engine.
Equip China,Power World!
