CAR GLASSES TEMPERING FURNACE FOR BACK WINDOW GLASS
US$ 330,000 - 440,000
/ Set
1 Set(Min. Order)
- Qingdao
- T/T Credit Card
You May Like
-
Automotive Windscreen Glass Tempering Bending furnace
-
Auto windshield Bending Glass Tempering furnace
-
Auto Double Curvature Bending Glass Tempering furnace with tooling
-
Single and Double Curvature Bending Glass Tempering furnace
-
Auto Rear Side Glass Single Double Curvature Glass Tempering furnace
-
Bi-direction Auto Rear Glass and Side window Double Curvature Glass Tempering furnace
Product Details
| Brand Name | Lever | Place of Origin | Henan, China | |
| Certification | CE | |||
| Warranty | 1 YEAR | Weight | 35000KGS | |
| Dimension(L*W*H) | 19390*6007*3300mm | Production Capacity | 98% | |
| Condition | New | Voltage | 380V | |
| Machine Type | Glass Tempering Furnace |
Product Description
Automotive Back Glass Double Curvature Glass Tempering Furnace
1. Machine Application:
Automotive Back Glass Double Curvature Glass Tempering Furnace, or called Mould Bent Glass Tempering Machine is a special plant used to produce the bent tempered glass with multi curvature, which mainly used in the fields of rear doors and side doors of automotives (the side door also is multi curvature), trucks, furniture, etc. Our customer produced the side doors for BMW, Audi, Toyota, Honda, Hyundai, Peugeot, etc.
2.Main Technical Features:
Loading Table:
1. Equipped with LED light to detect the glass with defects.
Heating Section:
1. Sectional driving for ceramic roller, the driving speed of last zone is faster than other zones.
2. Sectional heating, individual heating zones for each working position.
There are ceramic plates to divide the different heating zones,
3. There are ceramic plates at the top of oven, which could ensure more even heating, avoid dregs falling. But the cost is higher and has higher requirements on the installation.
4 The ceramic rollers system is driven by triple belts, which can ensure better simultaneous and stable running, and avoid the scratch and destroy of glass when above the rollers. It would not affect the running when any one of belt damaged. The design as below picture:
3. Same top quality insulating materials for whole heating oven
4. Heating elements use the gapless design (parallelogram shape), which could make the heating more even. This could improve the finished product rate and better product quality. The design as below picture:
Automotive Back Glass Double Curvature Glass Tempering Furnace, or called Mould Bent Glass Tempering Machine is a special plant used to produce the bent tempered glass with multi curvature, which mainly used in the fields of rear doors and side doors of automotives (the side door also is multi curvature), trucks, furniture, etc. Our customer produced the side doors for BMW, Audi, Toyota, Honda, Hyundai, Peugeot, etc.
2.Main Technical Features:
Loading Table:
1. Equipped with LED light to detect the glass with defects.
Heating Section:
1. Sectional driving for ceramic roller, the driving speed of last zone is faster than other zones.
2. Sectional heating, individual heating zones for each working position.
There are ceramic plates to divide the different heating zones,
3. There are ceramic plates at the top of oven, which could ensure more even heating, avoid dregs falling. But the cost is higher and has higher requirements on the installation.
4 The ceramic rollers system is driven by triple belts, which can ensure better simultaneous and stable running, and avoid the scratch and destroy of glass when above the rollers. It would not affect the running when any one of belt damaged. The design as below picture:
3. Same top quality insulating materials for whole heating oven
4. Heating elements use the gapless design (parallelogram shape), which could make the heating more even. This could improve the finished product rate and better product quality. The design as below picture:
5. Using ceramic support for heating elements, which could avoid earth to avoid heater trouble
Quenching Section:
1.Trumpet type air nozzle, which makes stronger air pressure, better quality, lower energy consumption, as below picture:
2. Round type air ducts, stronger air pressure, less air loss, lower energy consumption
Control System:
1. PLC, inverters. Contactors: Siemens
2. Network data for servo motor control mode: Profinet, compared with traditional wiring-connection, this mode could reduce disturbance
1. PLC, inverters. Contactors: Siemens
2. Network data for servo motor control mode: Profinet, compared with traditional wiring-connection, this mode could reduce disturbance
