Product Details
| Brand Name | GOGO | Place of Origin | Zhejiang, China | |
| Model Number | 373series | Material | Ceramic | |
| Application | General | Structure | Needle | |
| Standard or Nonstandard | Standard | |||
| Power | Manual | Port Size | Standard | |
| Media | Acid | Temperature of Media | Medium Temperature |
Product Description
Two position two way scientific process miniature electric air double solenoid valve
More series click here
Comprehensive Parameter
Valve position function | Two position two/three way, Normally closed (NC) or Normally open (NO) |
Way of working | Cut-off type |
Installation method | Free to install |
Drift Diameter | 0.7mm, 0.9mm, 1.2mm, 1.6mm |
Nominal Flow | 35L/min (when 6 bar), 19L/min (when 1.6 drift diameter, 2 bar) |
Work Pressure | 0-7 bar (NC), -100kpa (when used in vacuum need Special instrutions) |
Medium and ambient temperature | -5℃ - 50℃ (But Unfrozen) |
Working medium | Filtered compressed air (Filtration level in line with ISO8573-15.4.4), Or inert gas |
Response time | on < 8ms, off < 10ms |
Manual device | nil |
Materials contact with medium
Body | Engineering plastics PA66, PA12 |
Seals | FKM (fluororubber), NBR (Nitrile Butadiene Rubber) |
Internal Parts | Stainless steel, Copper |
Electrical Parameters
Voltage | DC6V, DC12V, DC24V, AC220V (As required) |
Voltage Tolerance | -5% - +10% |
Power Consumption | 0.75W, 1W (No energy saving module type), 0.3W (Energy saving modular, keep 0.3W) |
Work cycle | 100% can work continuously |
Electrical connections | Pins, sockets, or direct outlet type |
Degree of protection | IP50, IP65 (Straight line type) |
