Home > Products > Water solenoid valve GOGO > delphi control valv brake valve hks blow off valve
delphi control valv brake valve hks blow off valve
- 3000 Piece / Pieces per Month
- Ningbo
- T/T Credit Card
- Spring Close Handle Brass Ball Valve
- solenoid water valve 24v stainless gate valves price spirax sarco gate valve price
- Tankless Water Heater Isolation Valves,Threaded
- steelness steel valves self closing gate valve bronze seats for tyco valves
- septor male valve rubber seat check valve sant swing check valves
- small needle valve solenoid valves 2 way electric water automatic valve
Product Details
Brand Name: | GOGO | Place of Origin: | Zhejiang, China | Model Number: | MI-05 270 |
Material: | Brass | Structure: | Control | Standard or Nonstandard: | Standard |
Pressure: | Medium Pressure | Power: | Solenoid | Port Size: | 1/8" 1/4" 3/8" 1/2" |
Temperature of Media: | Medium Temperature |
Product Description
delphi control valv brake valve hks blow off valve
1. Brass ;
2. Stainless steel .
Specification
Pattern: | Two-port two-position | |||
Principium: | direct acting type | |||
Control mode: | normally close | |||
Valve body: | brass | |||
Diaphragm material: | NBR: ≤80°C ,FKM≤150°C | |||
Working pressure: | 0~10bar | |||
Max pressure: | 10bar | |||
Voltage: | AC220V AC110V DC12V DC24V | |||
Medium: | Air ,water ,Liquid ,oil ect. | |||
Application: | Gas protection welder, various types of burners, test equipment small-flow air water control system |
Model | Pipe | Orifice Diameter(mm) | Principium | CV | Body material | Seal | Work Pressure |
MI-03 | 1/8" 1/4" | 3 | direct acting | 0.3 | Brass , SS304 | NBR,FKM | 0-13bar |
MI-04 | 3/8" | 4 | 0.58 | NBR,FKM | 0-7bar | ||
MI-05 | 1/2" | 5 | 0.65 | NBR,FKM | 0-5bar | ||
MI-08 | 1/2" | 8 | 1.2 | NBR,FKM | 0-1bar |
Dimensions
(mm)
Orifice(mm) | A | B | C |
DN3 | 44 | 25 | 80 |
DN4 | 44 | 25 | 80 |
DN5 | 50 | 25 | 80 |
DN8 | 50 | 25 | 80 |
Materials of construction | |||
Parts in contact with the medium | |||
Valve of body | Brass | SS304 | |
Seals | NBR ,EPDM ,FKM | ||
Magnetic isolation pipe | SS304 | ||
Core | Stainless steel alloy | ||
Spring | SS304 | ||
The shading | Copper |
Port Size:3/8,1/2,3/4,1,1 1/4,1 1/2,2
Orifice (mm): 12,15,20,25,32,40,50
Sample is available for your testing
we can design valve as per your special requirement
SD01B, 35VA(AC),30W(DC),IP65,100%ED
SD02B,flying lead 35VA(AC),30W(DC),IP65,100%ED
small brass and plastic non return valves solenoid gas valve
- Inner packing: opp bag, then carton box for each product
- Outer packing: export standard carton, Foam outside protecting the goods against damage
- Usually we ship your order by sea or by air...
- We do our best to ship your order within 1 week after receiving your payment
- We'll tell you the tracking number once your order has been sent
- We accept T/T Bank transfer, L/C, Western Union, Moneygram, Paypal
- We have more than 12 years experience in solenoid valves
- Excellent quality control is one of our main principles
- Various style for each products and completely series pneumatic products for you to choose from
- Sample order & small quantity order is ok
- We provide OEM service, accept customer label, develop the product with your drawings or samples
- Any question, will be replyed within 24 hours
Founded in July,2014, Ningbo Fenghua GO GO Automatic company is a high-tech enterprise with all vitality, potential and comprehensive strength. The company is located in the Zhejiang Ningbo Science &Technology zone, a unique place with beautiful scenery and gifts of nature.
Main products of our company : automatic parts, pneumatic solenoid valve, air water solenoid valve, hydraulic valves, gear piston or vane pumps, fittings connectors, temperature pressure transmitter, temperature controller, PLC, DCS parts, hardware stainless steel or brass or plastic parts , etc.
Since its foundation, the company keeps living up to the belief of :"honest selling, best quality, people-orientation and benefits to customers. " We are doing everything to offer our customers with best services and best products. We promise that we'll be responsible all the way to the end once our services begin.
Q: What is your main market?
A: Our main market is north America, especially USA.
Q: Are you products standard?
A: Our model is standard, if you have specific demand, pls tell us.
Q: Do you have interest to do our own design items?
A: Absolutely! We have big interest.
Q: How to make the order?
A: You can send us email or inquiry at alibaba directly. for samples order, you can go to our aliexpress shop and place the order.
