Gas Taps 3way Stopcock Water Valves and Fittings
- Ningbo
- T/T Credit Card
You May Like
-
Bus Solenoid Valve Refrigeration Compressor Valve Plates Quarter-turn Electric Actuator
-
lp Gas Detector Solenoid Valve for Dishwasher Valve Assembly Machine
-
Oil Drum Valve Electric Heater Control Valve Urinal Flush Sensor
-
Four Way Valve Valve Core Water Level Regulator
-
1/4 Inch 3/2 Way Miniature Water Gas Brass Solenoid Valve
-
Dump Valve Crane Butterfly Valves Hatz Engine Parts
Product Details
| Brand Name | GOGO | Place of Origin | Zhejiang, China | |
| Model Number | MI-05 | Material | Brass | |
| Structure | Control | Standard or Nonstandard | Standard | |
| Pressure | Medium Pressure | Power | Solenoid | |
| Port Size | 1/8" 1/4" 3/8" 1/2" | |||
| Temperature of Media | Medium Temperature |
Product Description
gas taps 3way stopcock water valves and fittings
1. Brass ;
2. Stainless steel .
Specification
| Pattern: | Two-port two-position | |||
| Principium: | direct acting type | |||
| Control mode: | normally close | |||
| Valve body: | brass | |||
| Diaphragm material: | NBR: ≤80°C ,FKM≤150°C | |||
| Working pressure: | 0~10bar | |||
| Max pressure: | 10bar | |||
| Voltage: | AC220V AC110V DC12V DC24V | |||
| Medium: | Air ,water ,Liquid ,oil ect. | |||
| Application: | Gas protection welder, various types of burners, test equipment small-flow air water control system | |||
Electrical Specifications
1) Solenoid: 24 VAC.
2) Inrush volt-amp: 24 VAC - 11.50 VA.
3) Inrush current: 0.34 amp.
4) Hold ng volt-amp: 24 VAC - 5.75 VA.
5) Holding current: 0.2 amp.
Type : Normal Close Type
Aperture of Flow Rate : 2.5mm
Cv Value : 0.23
Joint Pipe Bore : 1/8" / 1/4" NPT is available
Operation Fluid Viscosity : below 20 CST
Working Pressure : 0~7 kgf/cm2
Max.Pressure Resistance : 10 kgf/cm2
Operating Temperature Range : -5~100℃
Dimensions
(mm)
chemicals
| food
| HVAC industry
| water treatment
|
environmental protection
| transport
| refrigeration industry
| pulp and paper
|
light industry
| water
| general services fields
| municipal engineering
|
petroleum
| the ship
| power
| industrial fields |
| Materials of construction | |||
| Parts in contact with the medium | |||
| Valve of body | Brass | SS304 | |
| Seals | NBR ,EPDM ,FKM | ||
| Magnetic isolation pipe | SS304 | ||
| Core | Stainless steel alloy | ||
| Spring | SS304 | ||
| The shading | Copper | ||
Compressed air,natural gases,water,hydraulic oil
New type solenoid valve, unique appearance, compact structure.
small brass and plastic non return valves solenoid gas valve
- Inner packing: opp bag, then carton box for each product
- Outer packing: export standard carton, Foam outside protecting the goods against damage
- We'll tell you the tracking number once your order has been sent
- We accept T/T Bank transfer, L/C, Western Union, Moneygram, Paypal
- We have more than 12 years experience in solenoid valves
- Excellent quality control is one of our main principles
- Sample order & small quantity order is ok
- We provide OEM service, accept customer label, develop the product with your drawings or samples
- Any question, will be replyed within 24 hours
Founded in July,2014, Ningbo Fenghua GO GO Automatic company is a high-tech enterprise with all vitality, potential and comprehensive strength. The company is located in the Zhejiang Ningbo Science &Technology zone, a unique place with beautiful scenery and gifts of nature.
Main products of our company : automatic parts, pneumatic solenoid valve, air water solenoid valve, hydraulic valves, gear piston or vane pumps, fittings connectors, temperature pressure transmitter, temperature controller, PLC, DCS parts, hardware stainless steel or brass or plastic parts , etc.
Since its foundation, the company keeps living up to the belief of :"honest selling, best quality, people-orientation and benefits to customers. " We are doing everything to offer our customers with best services and best products. We promise that we'll be responsible all the way to the end once our services begin.
Q: What is your main market?
A: Our main market is north America, especially USA.
Q: Are you products standard?
A: Our model is standard, if you have specific demand, pls tell us.
Q: Do you have interest to do our own design items?
A: Absolutely! We have big interest.
Q: How to make the order?
A: You can send us email or inquiry at alibaba directly. for samples order, you can go to our aliexpress shop and place the order.
solenoid gas valve
