Home > Products > Water solenoid valve GOGO > Wing Valve Ball Valve With Pneumatic Actuator Electrically Operated Solenoid Valve
Wing Valve Ball Valve With Pneumatic Actuator Electrically Operated Solenoid Valve
- Ningbo
- T/T Credit Card
You May Like
-
Baffle Valve Butter Fly Valve Brass Water Tank Float Valve
-
Radiator Auto Air Vent Valve Mini Motorized Ball Valve Low Pressure Air Check Valve
-
Rotex Solenoid Valve Solenoid Valve Price Gear Box Gate Valve
-
Two Way Check Valve Csa Approved Ball Valves Gas Cartridge Valve
-
Automatic Gas Shutoff Valve Modular Valve Hydraulic Knife Gate Valve
-
Hdpe Flap Valve Ball Valves for Water for Garden Hose Music Fountain Valve
Product Details
| Brand Name | GOGO | Place of Origin | Zhejiang, China | |
| Model Number | MI-05 | Material | Brass | |
| Structure | Control | Standard or Nonstandard | Standard | |
| Pressure | Medium Pressure | Power | Solenoid | |
| Port Size | 1/8" 1/4" 3/8" 1/2" | |||
| Temperature of Media | Medium Temperature |
Product Description
wing valve ball valve with pneumatic actuator electrically operated solenoid valve
1. Brass ;
2. Stainless steel .
Specification
| Pattern: | Two-port two-position | |||
| Principium: | direct acting type | |||
| Control mode: | normally close | |||
| Valve body: | brass | |||
| Diaphragm material: | NBR: ≤80°C ,FKM≤150°C | |||
| Working pressure: | 0~10bar | |||
| Max pressure: | 10bar | |||
| Voltage: | AC220V AC110V DC12V DC24V | |||
| Medium: | Air ,water ,Liquid ,oil ect. | |||
| Application: | Gas protection welder, various types of burners, test equipment small-flow air water control system | |||
Motion Pattern : Direct Drive Type
Type : Normal Close Type
Aperture of Flow Rate : 2.5mm
Cv Value : 0.23
Joint Pipe Bore : 1/8" / 1/4" NPT is available
Operation Fluid Viscosity : below 20 CST
Working Pressure : 0~7 kgf/cm2
Max.Pressure Resistance : 10 kgf/cm2
Operating Temperature Range : -5~100℃
Voltage: DC12V,DC24V,AC24V,AC36V,AC110V,AC220V,AC380V
Voltage Range : ±10%
Application
These durable, heavy-duty commercial valves offer a selection of key features designed to provide reliable, cost-effective performance under the most challenging.
Dimensions
(mm)
| Orifice(mm) | A | B | C |
| DN3 | 44 | 25 | 80 |
| DN4 | 44 | 25 | 80 |
| DN5 | 50 | 25 | 80 |
| DN8 | 50 | 25 | 80 |
| Materials of construction | |||
| Parts in contact with the medium | |||
| Valve of body | Brass | SS304 | |
| Seals | NBR ,EPDM ,FKM | ||
| Magnetic isolation pipe | SS304 | ||
| Core | Stainless steel alloy | ||
| Spring | SS304 | ||
| The shading | Copper | ||
small brass and plastic non return valves solenoid gas valve
- Inner packing: opp bag, then carton box for each product
- Outer packing: export standard carton, Foam outside protecting the goods against damage
- Usually we ship your order by sea or by air...
- We accept T/T Bank transfer, L/C, Western Union, Moneygram, Paypal
- We have more than 12 years experience in solenoid valves
- Excellent quality control is one of our main principles
- Various style for each products and completely series pneumatic products for you to choose from
- Sample order & small quantity order is ok
- We provide OEM service, accept customer label, develop the product with your drawings or samples
- Any question, will be replyed within 24 hours
Founded in July,2014, Ningbo Fenghua GO GO Automatic company is a high-tech enterprise with all vitality, potential and comprehensive strength. The company is located in the Zhejiang Ningbo Science &Technology zone, a unique place with beautiful scenery and gifts of nature.
Main products of our company : automatic parts, pneumatic solenoid valve, air water solenoid valve, hydraulic valves, gear piston or vane pumps, fittings connectors, temperature pressure transmitter, temperature controller, PLC, DCS parts, hardware stainless steel or brass or plastic parts , etc.
Since its foundation, the company keeps living up to the belief of :"honest selling, best quality, people-orientation and benefits to customers. " We are doing everything to offer our customers with best services and best products. We promise that we'll be responsible all the way to the end once our services begin.
Q: What is your main market?
A: Our main market is north America, especially USA.
Q: Are you products standard?
A: Our model is standard, if you have specific demand, pls tell us.
Q: Do you have interest to do our own design items?
A: Absolutely! We have big interest.
Q: How to make the order?
A: You can send us email or inquiry at alibaba directly. for samples order, you can go to our aliexpress shop and place the order.
solenoid gas valve
