Home > Products > Ungrouped > IEC60529 Waterproof Performance Water Splash IPX1 and IPX2 Drip Box Test Machine
IEC60529 Waterproof Performance Water Splash IPX1 and IPX2 Drip Box Test Machine
USD $1,000 - $9,900
/ Set
1 Set(Min.Order)
- 1000 Set / Sets per Month
- Shenzhen port Guangzhou port
- T/T Credit Card
You May Like
-
R 800 IEC60335 Waterproof IPX1 IPX2 Vertical Water Drip Test Equipment
-
Rain Grade IPX1 IPX2 IPX3 IPX4 IPX5 IPX6 IP Tightness Waterproof Test Chamber
-
Ip Rating Environmental Climatic Drip Box Waterproof Simulation Ipx1 Ipx2 Test Chamber
-
Drip IPX1 IPX2 Waterproof IP Rating Simulation Water Rain Proof Spray Tester
-
Simulation Environmental Ipx1 Ipx2 Ipx3 Ipx4 Jet Pluie Testing Equipment
-
Simulated Rainfall IPX1 IPX2 IPX3 IPX4 Rain Test Waterproof Climate Chamber
Product Details
| Brand Name: | Hongjin | Place of Origin: | Guangdong, China | Model Number: | HJ-12 |
| Power: | Electronic |
Product Description
Product Description
Application:
HONGJIN IPX12 rain drop Test Chamber is used for electronic and electrical products, lamps, electrical cabinets, electrical components, automobiles, motorcycles and their parts and components. Under the rain/drip environment,test the physical and other related properties of the product.
Main function
The main function of this IPX12 rain drop test equipment is to test the physical and other related properties of the products in the environment of simulated rain, such as electronic and electrical products, lamps, electrical cabinets, electrical components, automobiles, motorcycles and their parts and components. After the test, through the test to determine whether the performance of products meet the requirements in order to facilitate product design, improvement, testing and factory inspection.
Choose type:
1,IPX12A : 600mm/800mm/1000mm/1200mm ect adjust by your request
Size Information
Product specifications
Model | HJ-IP12-600 | HJ-IP12-1200 | |
Drip area | 600*600 mm | 1200*1200mm | |
Inner size | L800*D800*H1000mm | L1400*D1400*H1400mm | |
Outer size | About 1250*1000*1750mm | L2050*D1800*H2150mm | |
Turntable diameter | 600 mm | 800mm | |
Turntable bearing | 50KG | 50kg | |
Turntable lifting range | 350-700 mm | 650-1100mm | |
custom made | Customizable set of waterproof equipment | ||
Dripping aperture | 0.4mm | ||
Distance between holes | 20*20 mm | ||
Rainfall | 1-5 mm/min(±0.5mm/min) | ||
Flow adjustment mode | Manual | ||
Drop box height | stationary | ||
Turntable speed | 1 r/min(IPX1) | ||
Turntable tilt | 0° or 15° (horizontal direction) | ||
Testing times | 0-999 min | ||
Materials | SUS304 stainless steel | ||
Controller | 7inch touch screen | ||
Environment temperature | 5℃～35℃ | ||
Air pressure: 86kPa ~ 106kPa | |||
Voltage（V） | 220V | ||
Power（KW） | 1.0KW | ||
Standard | IEC60529:1989+A1:1999、GB4208、GB7000.（IPX1、IPX2) | ||
Related Products
Packing&Shipping
Before shipment, we will wipe the machine, spray rust remover, and package it with plastic film and foam paper to prevent the machine from colliding. Finally, we will put it into a reinforced fumigation-free export wooden box for export.
Company Introduction
Hongjin testing instrument was established in 2007, focusing on the development and production of environmental and mechanical testing instruments.
FAQ
