Product Details
| Brand Name | HY | Model Number | HYG-TH-80DH | |
| Power | Electronic |
wooden case
Product Description
lab equipment temperature rapid testing chamber
Simulate product in the condition of climatic environment (high and low temperature operation&storage,temperature loop,high temperature and humidity,low temperature and humidity, moisture condensation etc),inspect product adaptive capacity and character if change. Conform to international standard(IEC,JIS,GB,MIL)Reach international measurement program consistency (including test process,condition and method)
Structure performance:
Model | HY-TH-80 | HY-TH-150 | HY-TH-225 | HY-TH-408 | HY-TH-800 | HY-TH-1000 | |
Inner size: W×H×D(mm) | 40*50*40 | 50*60*50 | 60*75*50 | 60*85*80 | 100*100*80 | 100*100*100 | |
External size W×H×D(cm) | 105*165*98 | 105*175*108 | 115*190*108 | 135*200*115 | 155*215*135 | 155*215*155 | |
Temperature range | (low:A:+25℃; B:0℃;C:-20℃; D:-40℃;E:-60℃;F:-70℃) ( high :+100℃/+150℃) | ||||||
Temp analytic accuracy/uniformity | 0.1℃/±2.0℃ | ||||||
Temperature control accuracy | ±0.5℃ | ||||||
Heat; cooling time | Heat up about 4.0°C/min ; Cooling about 1.0°C/min | ||||||
Inner and outer materials | SUS#304 Stainless steel for inner chamber ; Carton Advanced cold plate nano paint for outer | ||||||
heat insulation material | Resistant to high temp ,high density,formate chlorine,ethyl acetum foam insulation materials | ||||||
cooling system | Air cooling/single segment compressor(-40°C) ,air and water double segment compressor (-50°C~-70°C) | ||||||
Protection devices | Fuse switch, compressor overload switch, refrigerant high and low pressure protection switch, super humidity over-temperature protection switch, fuse, failure warning system | ||||||
Parts | Watching window , 50mm testing hole , PL internal bulbs , Wet and dry bulb gauze , partition plate , castorx4,Foot Cupx4 | ||||||
Compressor | Original France"Tecumseh"brand | ||||||
Controller | TEMI South Korea | ||||||
Power | AC220V 50/60Hz & 1,AC380V 50/60Hz 3 | ||||||
weight (kg) | 150 | 220 | 270 | 320 | 450 | 580 | |
Our support is guaranteed for one year.
For all my customers, we will help you repair. Send us questions through text, images or videos, and we will tell you about them and help you fix them.
If the machine parts are damaged during the warranty period, we can send you a new machine parts free of charge. We have English specifications, online service personnel, video teaching of machine operation, and our machine operation is very simple.
1.What's your MOQ?
At present we haven't strict policy for this, so welcome orders with any quantity.
2. Are you a factory or trade company?
We are a manufacturer. You will be weclome to visit our facory or we also can let you see through video.
3. We are not professional for operation and installation of your machine?
While it is not a stumbling block, our machine is easy to operate, no need to professional training, and the instruction manual and video sent to you are enough. What's more, we have professional engineers and they can solve all questions.
4. How about packaging? If machine damaged, what should I do ?
Usually machine is packed with wooden case and standard export carton, plywood carton or as your requirement. Damage haven't happened before, if happen, we will arrange replacement.
5. We haven't do business before, how can I trust your company and machine?
We are a factory with more than 13 years and without amy complaints on Alibaba. and our machine have exported to many countries and have a good feedback.
6. If I want to visit your factory, is the traffic convenient ?
Our company traffic is very convenient, it is only 10 minutes by car or taxi from our city light rail to our company, if you come, I can give you a detail instruction.
7. Does your product have CE certification ?
Yes, all our products passed CE certification
8. If there is not any size meet my need, can I customiz ?
Yes, just provide me your detail requirement, we can do as yours.
