Solar panel deformation measurement testing machine Withstand pressure strength testing machinetesting equipment
Application
Usd for testing the module withstand wind , snow or ice and other static and dynamic load capacity in stalled in a different angle , it is widely used compressive strength test of PV moudle , adopt dynamic continuous pressure technilogy , simulated load test , so as get know the compressive load capacity of products under the state of load capacity
Load system
either pneumatically or vacuum or through using water or sand bag or any other acceptable method on the surface of the PV module under test
(Additional : Hydrostatic(water bag ) Mechanical Load Resistance will cost less money)
Technical Specifications
1.according to IEC 61215-2005,IEC 61646-2008,IEC 61730:2-2004 and UL 1703-2004
2. Be capable to accommodate PV module of dimensions up to 2700mm x 2000mm x 80mm
3.Power supply :230V ±10% , 415V ± 10%, 50 ±1HZ
4.Exterior dimensions :2900mm x 2200mm x 200mm
5. This machine be capable to create and vary pressure continuously from 10 to 6000Pa on the entire area of module
6.Provided onsite training,operation, maintenance and general servicing
Dongguan Hong Tu Instrument Co.,Ltd , specializes in developing and producing sales of testing instrument for helmet ,photovoltaic , leather ,footwear ,luggage ,sport equipments, metal and rubber , we have firm connections and full cooperation from China's National Third-part Quality Inspection and Notarization Center on producing and developing high-precision testing machines
We treasure the value of good quality , reasonable price and efficient service with customer satisfaction. we expert ourselves in providing our customers the best suitable testing designs and high quality testing machines to make you the utmost profit
Please feel free to contact us for any enquires from our wide range of products
1.High quality and best after-sell service
2.100% quality inspection before delivery
3.Managment Innovate
4.Strong R & D team
5.Can handle customers's feedback problems and doubt timely
6.Our testing machine have one year Warranty time
