Universal power cords bending tester cord machine

Universal power cords bending tester cord machine





Cable Plug Bending Testing Machine is  suitable for the plug pinouts, power cord, USB cable, headph-one

cable, audio cable, headphone cable and other products wire rod bending tests or swing test. The specimen

is fixed at fixture, and adding certain load, test swing around and through a few times, its outage, and view

the total number of oscillations, it can automatically count, try to bend to break when not powering on, and

automatically stop operation. Native UL817 related standards such as "cords General safety requirements

for components and power supply cords" provisions and general technical requirements for the headphone

wire bending tests of the standard GB/T14471-93.





Main Parameters —— Cable Plug Bending Testing Machine



Product name	Cable Plug Bending Testing Machine
Test stations	6 groups
Bending angle	0-180 ° adjustable
Test speed	10-60/min
Control system	Digital with LCD screen
Counter	0-999999
Load weight	50, 100, 200, 300, 500g
Machine weight	Approx 100kg
Power	AC220V, 50HZ







Features —— Cable Plug Bending Testing Machine

1.The Cabinet with electrostatic paint treatment, according to various standards of design, machine design

is reasonable, Fastening structure, safe, stable and accurate;

2.Counter can be preset, test, test automatic counting of conduction, reached number machine Stop with

power off memory function, convenient and practical;

3.Speed knob adjustable, LCD display, set customers according to their requirements, the user friendly

design;

4.Manually adjustable bending angle, indicates the needle indicates the scale dial, to better regulation;

5.Six stations while working independently, respectively, counting, one line, the corresponding counter; stop

counting machine as usual test, improve testing efficiency;

6.Six groups of nonslip, easy to damage materials specially designed handle, clamping products more

convenient, fast;

7.Test rods can be adjusted up and down, according to the standard requirements, and test better;

8.The distribution of weights with hook loading, multiple stacking, hanging more convenient.









1.Are your company a trading one or a factory ?

Factory + trade (integration),10 years focusing on test instruments field,3 years exporting experience.

OEM is also acceptable for us.

2.How to choose the most suitable products?

Our professional team will give you the best suggestion as long as you tell us what kind of test you

need to do and the required specification.

3.What’s the delivery term?

At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20

working days after deposit receipt. If you are in urgent need, we can consider making special

arrangement for you.

4.Do you accept customization service?

Yes, of course, we can not only offer standard machines, but also customized machines according to

your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.

5.Can we visit your factory before order?

Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to

arrange hotel and pick up you from airport.

6.Do you have customers of our country before?

Now our testing machines have been sold to more than 26 countries, like USA, Canada, Russia,UK,

Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand and Vietnam,Iran,

Brazil and so on.

7.How about your warranty?

Generally, our warranty is one year. Within the warranty period, we can offer technique support and

part parts change, necessarily, our engineers may go to your place for better service.

8.How about the packing for machine, is it safely protected during transportation?

Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many

testing machines abroad by sea or by air without damage.

9.What is the order process?

Inquiry - quotation - communication - order confirming - deposit payment - production - testing and

debugging - balance payment - packing - delivery - customer receiving - after service.

10.How to install and use the product

The product is shipped with an operating instructions and video of English version.
