Widely used rubber peeling strength seal peel testing machine
Overview:
Peel Strength Testing Machine, Adhesie Tape 90 Degree 180 Degree PeelingTester is used to quantify the permanence of adhesion or peel ability of self- adhesive pressure sensitive materials. Peel adhesion is defined as the force required for removing a pressure sensitive coated material.
Application:
Peel Strength Testing Machine, Adhesie Tape 90 Degree 180 Degree PeelingTester is used to quantify the permanence of adhesion or peel ability of self- adhesive pressure sensitive materials. Peel adhesion is defined as the force required for removing a pressure sensitive coated material, which has been applied to a standard test plate under specified conditions, from the plate at a specified angle and speed. Presto Adhesion Strength Tester is strictly manufactured as per ASTM standards and is highly recommended for use in the plastic packaging industry.
Specifications:
| Items | Adhesie Tape 90 Degree 180 Degree PeelingTester |
| Capacity | 2, 5, 10, 20, 50, 100, 200Kg |
| Unit | G, KG, N, LB can be exchanged |
| Accurate Grade | 0.5grade |
| Display Device | PC |
| Resolution | 1/250,000 |
| Effective Accuracy | ±0.2%(0.5grade) |
| Max.Stroke | 600mm |
| Speed Range | 0.01-500mm/min (adjustable ) |
| Motor | Servo Motor + High Precise Ball Screw |
| Elongation Accuracy | 0.001mm |
| Power | AC220V, 50/60HZ(custom-made) |
| Standard Accessories | 90 or 180 degree peel test clamps, Computer system, English software CD, |
| User manual |
Application Standard:
D3359 - 17: Standard Test Methods for Rating Adhesion by Tape Test
ASTM-D3330: Standard Test Method for Peel Adhesion of Pressure-Sensitive Tape
Pstc -101: International Standard for Peel Adhesion of Pressure Sensitive Tape
ASTM-D1876: Standard Test Method for Peel Resistance of Adhesives
Etc...
1.Are your company a trading one or a factory ?
Factory + trade (integration),10 years focusing on test instruments field,3 years exporting experience.
OEM is also acceptable for us.
2.How to choose the most suitable products?
Our professional team will give you the best suggestion as long as you tell us what kind of test you
need to do and the required specification.
3.What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20
working days after deposit receipt. If you are in urgent need, we can consider making special
arrangement for you.
4.Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines according to
your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
5.Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to
arrange hotel and pick up you from airport.
6.Do you have customers of our country before?
Now our testing machines have been sold to more than 26 countries, like USA, Canada, Russia,UK,
Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand and Vietnam,Iran,
Brazil and so on.
7.How about your warranty?
Generally, our warranty is one year. Within the warranty period, we can offer technique support and
part parts change, necessarily, our engineers may go to your place for better service.
8.How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many
testing machines abroad by sea or by air without damage.
9.What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and
debugging - balance payment - packing - delivery - customer receiving - after service.
10.How to install and use the product
The product is shipped with an operating instructions and video of English version.
