Factory Price High Precision Plastic Digital Charpy Impact Tester, Impact Testing Machine
Summary:
Factory Price High Precision Plastic Digital Charpy Impact Tester, Impact Testing Machine for sale is mainly used for the determination of impact toughness of non-metallic materials such as hard plastic, reinforced nylon, glass reinforced plastic, ceramic, cast stone and electrical insulating materials. It is an ideal test equipment for chemical industry, scientific research units, universities and colleges, and quality inspection departments.
This tester has a clear function; energy loss measurement and automatic compensation function; strength, standard deviation, and other functions automatically calculate impact. CHARPY clamp jaws wedge from mouth, clamping freely, fast clamping, is the latest development of our new products.
Standard:
ISO179-2000, GB/T1043-2008, JB/T8762-1998, GB/T 18743-2002, ISO180-2000, GB/T1843-2008, JB/T8761-1998, ASTM D256-2010 ETC.
Specifications:
Impact energy | 7.5J15J20J50J |
Display mode | Color touch screen |
Accuracy | 0.01J |
Impact velocity | 3.8m/s |
Pendulum elevation | 150° |
Support blade corner radius | R = 1mm |
Impact center distance | 395mm |
Blade fillet radius | R=2mm ± 0.5mm |
Angle accuracy | Original OMRON encoder, 0.01° |
Power | 220V±10% 50HZ |
Features:
1. High-precision intelligent controller with LCD display for intuitive and accurate data reading.
2. The first domestic use of carbon fiber pendulum (patent applied), in the impact direction, to improve the
rigidity of the material, and the impact quality is concentrated on the centroid of the pendulum, truly
vibration-free impact test, and the service life increases.
3. Imported high-resolution digital encoder, the angle test accuracy is higher and more stable.
4. Aerodynamic impact hammer and imported ball bearing, greatly reducing the friction loss caused by the
machine.
5. Automatically calculate the final result, the test data can save 12 sets of data and average.
6. Can choose Chinese and English operation interface, test results can choose J / m, KJ / m2, kg-cm / cm,
ft-ib / in and other units.
7. Built-in micro printer print test data.
Images
Customer case 1
Customer case 2
Factory Price High Precision Plastic Digital Charpy Impact Tester, Impact Testing Machine
Factory Price High Precision Plastic Digital Charpy Impact Tester, Impact Testing Machine
Factory Price High Precision Plastic Digital Charpy Impact Tester, Impact Testing Machine
We have professional packing teams and shipping forwarder to pack and deliver your products!
Packing:
1. Out packing:Standard export wooden case.
2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.
Shipping:
You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt ofyour order. It's more preferable for you to provide us with your own FEDEX/DHL account number so that the delivery charge can be charged directly from your account.
1.Are your company a trading one or a factory ?
Factory + trade (integration),12 years focusing on test instruments field,5 years exporting experience.
OEM is also acceptable for us.
2.How to choose the most suitable products?
Our professional team will give you the best suggestion as long as you tell us what kind of test you
need to do and the required specification.
3.What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20
working days after deposit receipt. If you are in urgent need, we can consider making special
arrangement for you.
4.Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines according to
your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
5.Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to
arrange hotel and pick up you from airport.
6.Do you have customers of our country before?
Now our testing machines have been sold to more than 120 countries, like USA, Canada, Russia,UK,
Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand and Vietnam,Iran,
Brazil and so on.
7.How about your warranty?
Generally, our warranty is one year. Within the warranty period, we can offer technique support and
part parts change, necessarily, our engineers may go to your place for better service.
8.How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many
testing machines abroad by sea or by air without damage.
9.What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and
debugging - balance payment - packing - delivery - customer receiving - after service.
10.How to install and use the product
The product is shipped with an operating instructions and video of English version.
Digital Type Charpy Impact Tester, Charpy impact tester for sale
Digital Type Charpy Impact Tester, Charpy impact tester for sale
Digital Type Charpy Impact Tester, Charpy impact tester for sale
