Home > Products > AC Servo Products > 380VAC 1000rpm 3.7KW 10A Synchronous Brushless Print Machine Mige Dorna ac Servo System
380VAC 1000rpm 3.7KW 10A Synchronous Brushless Print Machine Mige Dorna ac Servo System
- T/T Credit Card
You May Like
-
1.2w 220v 3000rpm Teco Digit Amt806 Inova Mini Flang Delta Xinj Mige ac Servo Motor
-
220VAC 1500rpm 5.5KW 24A Mini Dorna ac Servo Motor Ethercat Sgmg Generator
-
380VAC 1500rpm 5.5KW 12A 5000 Watt ac Automation Voltage Regular Stability Avr Servo Motor Svc
-
220VAC 1500rpm 7.5KW 32A ac Automat Voltage Regular Stability Avr Servo Motor Price
-
800w 220v 2000rpm Reduce 3 Phase Synchronous Generator Kit Control Small ac Servo Torque Motor
-
1.2kw 3000rpm Embroidery Mhin Used Motion Bautz 3 Phase Harga Oem 220v Digital for Router Teco ac Servo Motor
Product Details
| Brand Name | PrimoPal | Place of Origin | Shanghai, China | |
| Model Number | PAS180-437010 | Type | Servo Motor | |
| Frequency | 50/60HZ | Efficiency | IE 3 | |
| Certification | CCC, CE, ROHS, UL, VDE | |||
| Phase | Three-phase | Protect Feature | Waterproof |
Product Description
PrimoPal offers a wide selection of high-performance brushless AC servo motors, with power ratings from 200 W to 7.5 KW, output torque from 0.16 Nm to 67 Nm, and maximum speed of up to 6,000 rpm. These motors are designed for outstanding efficiency, reliability and electromagnetic immunity, particularly suitable for positioning tasks in machine automation with demanding requirements for dynamics and stability. The combination of PrimoPal’s servo motors and servo drives delivers an optimal solution for high performance motion applications. Besides, custom motor winding, various feedback devices, permanent magnet brake adders, electromagnetic brake adders and mechanical modifications are also available.
| Operating Temperature | -20°C ~ 50°C |
| Insulation Class | Class B (130°C) |
| Safety Grade | IP65 |
AC servo motor without brake
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
AC servo motor with brake
