TD05H 20G 49179-43400 52.56/68.01mm 6+6 Blades Reverse Turbo Performance Design Aluminum 2618/milling/billet Compressor Wheel
US$ 60 - 60
/ Piece
1 Piece(Min. Order)
- T/T Credit Card
You May Like
-
T04E 62.45/82.36mm 7+7 Blades High Performance Turbocharger Billet/milling/aluminum 2618 Compressor Wheel For GTX3582 Turbo
-
K04 46.39/60.00mm 5306-123-2014 Upgrade 5304-970-0064 Upgrade 6+6 Blades Aluminum 2618/milling/billet Compressor Wheel
-
TD05H 18G Reverse 50.39/68.01mm 11+0 Blades High Performance High Blade Turbo Milling/aluminum 2618/billet Compressor Wheel
-
TD05H 16G 49178-01560 48.30/68.01mm 6+6 Blades Turbo Milling/Aluminum 2618/billet Compressor Wheel
-
T88 34D 11+0 Blades 69.67/95.00mm High Performance Turbo Billet/milling/aluminum 2618 Compressor Wheel for 49188-02700
-
TD04HL 42.00/56.00mm 7+7 Blades High Performance Turbo Billet/milling/aluminum 2618 Compressor Wheel
Product Details
| Brand Name | NO | Place of Origin | Shanghai, China | |
| Model Number | TD05H 20G | Warranty | 12 Months |
Product Description
Product Description
1. MODEL:TD05H 20G reverse
2.TD05H 20G reverse 52.56/68.01mm 49179-43400 6+6 blades high performance Turbo Billet/milling/aluminum 2618 compressor wheel
3.Size:
Nose diameter:13.50mm
Inducer:52.56mm
Exducer:68.01mm
Tapered tip exducer:73.05mm
Tip height:5.37mm
Superback:2.90mm
Overall height:35.00mm
bore size :6.50mm
Trailing Angle:45
Cutback:0.0
SP height angle:-8.50
Splitter height:20.20mm
Blades height :28.90mm
6+6 BLADES.
FIT FOR OE compressor housing
Reverse rotation
Tapered tip angle:30 degree
4.High quality and competitive price.
5.if you want more details, please send email to me.
All the compressor wheel have been balanced.
