COMMON RAIL INJECTOR TEST BENCH DTS709

DTS709 COMMON RAIL TEST BENCH is mainly test for common rail injector. Also it is continuous fuel delivery analysis computerised measuring system for conventional and new diesel injection systems. The electronic fuel delivery measuring system is compulsory for modern diesel injection system testing.It guarantees a high level of reproductivity of the measured value

Function
1.Test injector brands: SIEMENS, DELPHI, DENSO.
2. Test 1 piece of injector.
3. Test the pre-injection of common rail injector.
4. Test the max. oil quantity of common rail injector.
5. Test the cranking oil quantity of common rail injector.
6. Test the back flow oil quantity of common rail  injector.
7.Test the average oil quantity of common rail injector.
8. Test the seal performance of common rail injector.
9. Data can be searched and saved.

ØTechnical parameter
1. Pulse width: 0.1~20ms
2. Continuous injection times: 0~1000
3. Fuel temperature: 40±2℃
4. Rail high pressure: 0~1600 bar
5. Test oil filtered precision: 5μ
6. Input power: 380V/50hz/3phase or 220V/60hz/3phase
7. Rotation speed: 0~3000RPM
