CR816 6 Cylinders Diesel Common Rail Injector Pump EUI EUP HEUI Test Bench Bank Stand

WOODEN CASE

CR816 6 cylinders diesel common rail injector pump EUI EUP HEUI test bench bank stand

CR816multifunctional test bench mainly test for common rail pump and Injector, HEUI,EUI/EUP.Also it is continuous fuel delivery analysis computerised measuring system for conventional and new diesel injection systems. The electronic fuel delivery measuring system is compulsory for modern diesel injection system testing. It guarantees a high level of reproductivity of the measured Value.

1.Introduction

· Function

1. Imported flow sensor test flow, reliable quality, good repeatability.

2. Comprehensive testing. Can test injector full load, medium speed, idle, pre-spray and other conditions of the fuel injection

3. Use a wide range. Can detect Bosch, Denso, Delphi, Siemens, CAT, such as injector

4. Low noise, the host uses frequency control, low speed and high torque, speed prefabrication, low noise, no impact.

5. Advanced control, a key to select, the whole process of automatic detection

6. Massive data, a total of more than 1,700 kinds of fuel injector data.

7.  data management. The user can according to the guidelines, add their own fuel injector technical indicators, especially for the new fuel injector standard fuel calibration

8. Equipped with oil pump flow sensor, with the use of rail pressure sensor, you can complete the high-pressure common rail pump test

9. Pump type test, through different couplings, different connection flange, can test different types of high-pressure pump, such as CP1, CP2.CP3, HP0, etc.

10. The pump can automatically complete the test conditions, such as the maximum flow, economic flow, zero oil, and the formation of statements.

11. With the CAMBOX mechanism and adapter, it can test EUI/EUP injector(on request)

12 With the mechanism and adapter, it can test HEUI(on request)

13.it can use high pressure rail and sensor  to test high pressure injector(on request)

14.With printer It can print the test result

 · Technical parameter

1. Rated output power: 7.5KW ,11KW,15KW,18.5KW (on request)

2. Electronic power: 3PHASE 380V 50HZ OR 3PHASE 220V 60HZ

3. Motor speed: 0-4000RPM

4. Pressure adjustment: 0-2500bar

5. Fuel temperature: 40 ±2℃

6.Flow testing range:0-600ml/1000times

7.Flow measurement accuracy:0.1ml

8. Filter accuracy: less than 5um

9.Cooling system: fan or forced cooling

10. Fuel tank capacity: 60L

11.. Size: 1900MM * 900MM * 1500MM

9. Weight: 800kg

10. With 19-inch display

11. Adopt interference-free Logitech mouse
