LS550G 550kw Generator Set With KTAA19-G6A Engine 688kva Genset

LS550G 550kw Generator Set With KTAA19-G6A Engine 688kva Genset thumbnail-1
LS550G 550kw Generator Set With KTAA19-G6A Engine 688kva Genset thumbnail-2
LS550G 550kw Generator Set With KTAA19-G6A Engine 688kva Genset thumbnail-3
LS550G 550kw Generator Set With KTAA19-G6A Engine 688kva Genset thumbnail-4
LS550G 550kw Generator Set With KTAA19-G6A Engine 688kva Genset photo-1
LS550G 550kw Generator Set With KTAA19-G6A Engine 688kva Genset photo-2
LS550G 550kw Generator Set With KTAA19-G6A Engine 688kva Genset photo-3
LS550G 550kw Generator Set With KTAA19-G6A Engine 688kva Genset photo-4
US$ 5,000 - 35,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Longshine
Place of Origin:
Chongqing, China
Model Number:
LS550G
Contact Supplier Request Quote Chat Now
Chongqing Longshine Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Longshine
Place of Origin Chongqing, China
Model Number LS550G
Speed 1500rpm

LS550G 550kw Generator Set with KTAA19-G6A Engine 688kva Genset

Product Description



Generator Model LS550G
Engine Model KTAA19-G6A
Rated speed 1500rpm
Fuel Consumption(L/h) 122
Prime Power 470KW/588KVA
Standby Power 550KW/688KVA
Length(mm) 3400
Width(mm) 1550
Height(mm) 2100
Net Weight(kg) 3770



Detailed Pictures
 LS550G 550kw Generator Set with KTAA19-G6A Engine 688kva Genset
LS550G 550kw Generator Set with KTAA19-G6A Engine 688kva GensetLS550G 550kw Generator Set with KTAA19-G6A Engine 688kva Genset

Standard Generator Set List
Generator Model Engine Model Standby Power Prime Power Speed    Fuel Consumption
kW kVA kW kVA rpm L/h
LS36G 4BT3.9-G2 36 45 32 40 1500  8
LS140G 6CTA8.3-G2 140 175 120 150 1500  30
LS160G 6CTA8.3-G2 160 200 140 175 1800  36
LS220G NT855-GA 220 275 200 250 1500  41
LS250G NTA855-G1A 250 313 220 275 1500  55
LS280G NTA855-G1 280 350 250 313 1800  61
LS280G MTAA11-G3 280 350 250 313 1500  61
LS300G NTA855-G1B 300 375 275 344 1800  68
LS300G NTA855-G2A 300 375 275 344 1500  68
LS400G KTA19-G2 400 500 360 450 1800  85
LS400G KTA19-G3 400 500 360 450 1500  85
LS450G KTA19-G3A 450 563 400 500 1500  98
LS450G KTA19-G3 450 563 400 500 1800  98
LS450G KTA19-G4 450 563 400 500 1500  98
LS550G KTAA19-G5 550 688 470 588 1800  117
LS660G KTA38-G2 660 838 600 750 1500  147
LS710G KTA38-G2B 710 888 640 800 1500  160
LS880G KTA38-G5 880 1100 800 1000 1500  200
LS1100G KTA50-G3 1100 1375 1000 1250 1500  245
LS1100G QSK38-G5 1150 1438 960 1200 1800  240
LS1320G KTA50-G8 1320 1650 1100 1375 1500  294
LS1320G KTA50-GS8 1320 1650 1200 1500 1500  300

Controller

LS550G 550kw Generator Set with KTAA19-G6A Engine 688kva Genset

Alternator

LS550G 550kw Generator Set with KTAA19-G6A Engine 688kva Genset

All Generator Set

LS550G 550kw Generator Set with KTAA19-G6A Engine 688kva Genset

Our Factory

LS550G 550kw Generator Set with KTAA19-G6A Engine 688kva Genset
